66.22.8.230.0000 Finder Control Relays

66.22.8.230.0000 on Powermatic Associates
Finder

Part#:66.22.8.230.0000

Manufacturer:Finder

Category:Control Relays

Product Lifecycle:Active

Product description

Electromechanical power relay - Finder (66 series) - Control coil voltage 230Vac (50Hz/60Hz) - 2 poles (2P) - 2C/O / DPDT (Double Pole Double Throw) contact - Rated current 30A (250Vac; AC-1; NO contact)|10A (250Vac; AC-1; NC contact) / 25A (30Vdc; DC-1;

Product Details

  • Main function
    Relay
  • Rated power
    1200VA (230Vac; AC-15; NO contact) 7500VA (250Vac; AC-1; NO contact) 2500VA (250Vac; AC-1; NC contact) 3.6W
  • Primary brand
    Finder
  • Connection type
    Solder pin bifurcated
  • Contacts type
    2C/O / DPDT (Double Pole Double Throw)
  • Mechanical durability (at no load)
    10 000 000 operations
  • Control Voltage (AC)
    230Vac (50Hz/60Hz)
  • Rated voltage (AC)
    250Vac
  • Net Height (mm)
    31 mm
  • Product series / family name
    66 series
  • Poles
    2 Pole(s)
  • Net Depth (mm)
    33.5 mm
  • Rated impulse voltage (Uimp)
    4 kV
  • Mounting mode
    PCB
  • Contacts coating
    AgCdO (Silver Cadmium Oxide)
  • Electrical durability (with load)
    100 000 operations
  • Compliant with standard(s)
    cURus RINA IMQ CSA VDE EAC CE EN 60335-1 EN 60664-1 EN 61000-4-5 EN 61810-1
  • Rated current
    30A (250Vac; AC-1; NO contact) 10A (250Vac; AC-1; NC contact) 25A (30Vdc; DC-1; NO contact) 0.7A (110Vdc; DC-1; NO contact) 0.3A (220Vdc; DC-1; NO contact)
  • Ambient air temperature for operation
    -40...+70 °C
  • Power consumption
    3.6 W
  • Net Width (mm)
    51.5 mm

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
