77.25.8.230.8250 Finder Control Relays

77.25.8.230.8250 on Powermatic Associates
Finder

Part#:77.25.8.230.8250

Manufacturer:Finder

Category:Control Relays

Product Lifecycle:Active

Product description

Finder 77.25.8.230.8250 is a Solid State Relay (SSR) designed for modular DIN rail mount applications. It features a single Normally Open (NO) circuit with a screw-clamp connection type. The rated current for this SSR is 25A at 230Vac (AC-1), and it operates with a single pole single throw - normally open (SPST-NO) configuration. The ambient air temperature range for operation is from -30 to +80°C, and it is designed to work within a control voltage of 230Vac. This SSR has a rated impulse voltage (Uimp) of 5.6 kV and dimensions of 57.7 mm in length, 44.5 mm in net width, and 36.4 mm in poles width. It offers protection functions for one pole and supports zero-cross switching capability for AC switching. The mounting mode is specified for heatsink or panel installation.

Product Details

  • Product series / family name
    77 series
  • Number of Normally Open (NO) circuits
    1 NO Pole(s)
  • Functions
    Modular DIN rail mount Solid State / Static Relay (SSR)
  • Poles
    1 Pole(s)
  • Degree of protection
    IP20
  • Rated impulse voltage (Uimp)
    5.6 kV
  • Net Width (mm)
    44.5 mm
  • Primary brand
    Finder
  • Connection type
    Screw-clamp
  • Ambient air temperature for operation
    -30...+80 °C
  • Rated voltage (AC)
    230Vac
  • Mounting mode
    Heatsink or panel
  • Net Depth (mm)
    36.4 mm
  • Control Voltage (AC)
    230Vac (50Hz/60Hz)
  • Technology used in component
    Zero-cross switching capability (for AC switching)
  • Contacts type
    1NO / SPST-NO (Single Pole Single Throw - Normally Open)
  • Compliant with standard(s)
    cURus EAC CE EN 60947-4-3 EN 61000-4-2 EN 61000-4-3 EN 61000-4-4 EN 61000-4-5 EN 61000-4-6 EN 62314
  • Main function
    Solid State Relay (SSR)
  • Rated current
    25A (230Vac; AC-1)
  • Net Height (mm)
    57.7 mm

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
