AB7500-F HMS Networks Industrial Automation Components

Product Details

• Manufacturer description
  Anybus X-Gateways - Network 1 PROFINET IRT Slave 2 Port / Network 2 Profibus Master
• Primary brand
  eWON by HMS Networks
• Customs Tariff Number
  8517620090
• Net Width (ERP) (mm)
  44 mm
• Storage Temperature °C Max
  85 °C
• Protection Class IP
  IP20
• Export Control Classification Number (ECCN) (ERP)
  5A991.b.1
• PROFINET Output Data Size
  512 bytes
• Current Consumption Max value at Vcc nom (mA)
  400mA @ 24V DC
• Operating Temperature °C Max
  65 °C
• Waste Certification (WEEE)
  Yes
• Dual Usage (ERP)
  No
• PROFINET Configuration File
  GSDML available
• Net Height (ERP) (mm)
  127 mm
• Short Circuit Protection
  Yes
• Packaging Material
  Cardboard
• Recycle / Disposal
  TRUE
• PROFIBUS Device Address
  0-125
• Net Weight (ERP) (g)
  400 g
• Housing Materials
  Aluminum, Plastic
Environment
EN 61000-6-4, EN 55016-2-3 Class A, EN 55022 Class A, EN 61000-6-2, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6
PROFIBUS Mode
Master
PROFINET Supported Functionality
IRT, SNMP
Net Depth (ERP) (mm)
114 mm
Reverse Polarity Protection
Yes
EMC
Yes
Country of Origin
Sweden
PROFIBUS No. Of Devices
125
Input Voltage (V)
24V DC (-20% to +20%)
UL
Yes
WEEE Category
IT and telecommunications equipment
HS Code
8517620000
PROFIBUS Output Data Size
512 bytes
Current Consumption Type Value at Vcc Nom (mA)
200mA @ 24V DC
Operating Temperature °C Min
-25 °C
CE
Yes
Connectors / Input / Output
1x D-sub 9-pin male and 1x D-sub 9-pin female, 2x RJ45, USB-B Config port
PROFIBUS Input Data Size
512 bytes
Mounting
DIN-rail (EN 50022 standard)
Storage Temperature °C Min
-40 °C
RoHS Compliant
Yes
PROFIBUS Supported Functionality
PROFIBUS DP Master functionality according to IEC 61158;Acyclic Communication (DP-V1, Class 1 & 2);LiveList;ControlStatus
PROFINET Mode
Slave
Isolation
TRUE
FCC
No
Contains Battery
No
PROFIBUS Configuration File
GSD available
PROFINET Input Data Size
512 bytes
Power Connector
2-pin, 5.08 Phoenix plug connector
UL File Number
E214107: Ord.Loc UL508, CSA C22.2 NO. 142
PROFIBUS Baud Rate
9600 bit/s - 12 Mbit/s
PROFINET Bandwidth
100MBit full duplex down to 1ms cycle time
