ABC3261-A HMS Networks Industrial Automation Components

Product Details

• Net Weight (ERP) (g)
  150 g
• Short Circuit Protection
  Yes
• Housing Materials
  PC ABS, UL 94 VO
• UL File Number
  E214107: Ord.Loc UL 61010-1, CSA C22.2 No. 61010-1, UL 61010-2-201, CSA C22.2 No. 61010-2-201
• Protection Class IP
  IP20, IP54
• Contains Battery
  No
• Export Control Classification Number (ECCN) (ERP)
  5A991.b.1
• Modbus-TCP Mode
  Master / Client
• Modbus-TCP No. Of Servers
  152 transactions / 64 connections
• Mounting
  DIN-rail (EN 50022 standard)
• Current Consumption Max value at Vcc nom (mA)
  125mA @24V DC (3W)
• Storage Temperature °C Min
  -40 °C
• ATEX
  No
• EMC
  Yes
• Push Buttons
  Factory reset
• EtherCAT Supported Functionality
  COE (Can Over EtherCAT); PDO, SDO; APRD, ARMW, APWR, BRD, BWR, FPRD, FPRW, FPWR, FRMW, LRD, LRW, LWR
• Modbus-TCP Input Data Size
  1500 bytes
• Recycle / Disposal
  TRUE
• EtherCAT Input Data Size
  1486 bytes
• UL
  Yes
EtherCAT Output Data Size
1486 bytes
Reverse Polarity Protection
Yes
Environment
EN 55016-2-3 Class A, EN 55032 Class A, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6
DIP & Rotary Switches
Security lock switch
Modbus-TCP Bandwidth
10/100 Mbit/s down to 10ms
Operating Temperature °C Max
70 °C
Country of Origin
Sweden
EtherCAT Bandwidth
10/100 Mbit down to 100us cycle time
Modbus-TCP Functions Supported
1, 2, 3, 4, 5, 6, 15, 16, 23
Input Voltage (V)
12-30V DC
Storage Temperature °C Max
85 °C
KC
Yes
Predecessor
AB9000-B, AB9000-B-5PACK
Modbus-TCP Supported Functionality
Modbus specification V1.1B; Endian Conversion (Byte swap); LiveList; DataExchangeControl
Dual Usage (ERP)
No
Current Consumption Type Value at Vcc Nom (mA)
90mA @ 24V DC (2.2W)
Waste Certification (WEEE)
Yes
Model Code
40-ETH-ETH-B
Isolation
TRUE
Operating Temperature °C Min
-25 °C
Warranty (years)
5
CE
Yes
WEEE Category
IT and telecommunications equipment
FCC
No
HS Code
8517620000
EtherCAT Configuration File
ESI available
Modbus-TCP Output Data Size
1500 bytes
Power Connector
3-pin, 5.08 Phoenix plug connector
Packaging Material
Cardboard
RoHS Compliant
Yes
EtherCAT Mode
Slave / SubDevice
Connectors / Input / Output
2xRJ45, 2xRJ45, RJ45 Config port
