AWB3006-B HMS Networks Industrial Automation Components

Product Details

• Net Depth (ERP) (mm)
  33 mm
• Storage Temperature °C Min
  -40 °C
• FCC
  Yes
• Max No. Of Connections
  7
• RF Output Power (LE)
  10 dBm EIRP (including max antenna gain 3 dBi)
• HS Code
  8517620000
• Mounting
  Wall mount
• Packaging Material
  Cardboard
• Operating Temperature °C Min
  -30 °C
• Frequencies & Bands
  2.4 GHz Access Point: 1–11 2.4 GHz Client: 1–11 + 12 & 13 depending on regulatory domain scan 5 GHz Access Point: 36–48 (U-NII-1) 5 GHz Client: 36-48 + 100–116, 132–140, 120–128 depending on regulatory domain scan. (UNII-1, U-NII-2, U-NII-2e)
• Contains Battery
  No
• Net Data Throughput
  ~1 Mbps
• Net Data Throughput (LE)
  ~200 kbps
• Operating Temperature °C Max
  65 °C
• CE
  Yes
• Country of Origin
  Sweden
• Net Width (ERP) (mm)
  68 mm
• RED
  Yes
• Operation Mode
  Access Point, Client
• Operation Mode (LE)
  Access Point, Client
Security (LE)
AES-CCM cryptography
Net Weight (ERP) (g)
102 g
Housing Materials
Plastic
Bluetooth Version (LE)
Bluetooth v4.0
Export Control Classification Number (ECCN) (ERP)
5A992.c
Content of Delivery
Quick start documentation Power supply not included
Antenna
Included
Environment
EN 61000-6-2:2019 EN 61000-4-2:2009 EN 61000-4-3:2006 + A1:2008 + A2:2010 EN 61000-4-4:2012 EN 61000-4-5:2014 EN 61000-4-6:2014 EN 61000-6-4:2019 EN 55016-2-3:2017 EN 55032:2015 EN 301 489-1 V2.2.3 EN 301 489-17 V3.1.1
RF Output Power
14 dBm EIRP (including max antenna gain 3 dBi)
Security
Authentication & Authorization, Encryption & Data Protection, Privacy & Confidentiality, NIST Compliant, FIPS Approved
Warranty (years)
3
UL
Yes
Connectors / Input / Output
1x M12 for Ethernet (4-pin, D-coded) 1x M12 for Power 5-pin, A-coded)
Power Consumption (W)
1.7W
ATEX
Yes
Approved Radio Certificates (Country)
Europe, USA, Canada, Japan, Australia, Colombia, Turkey, Malaysia, Peru, Mexico, Argentina, Brazil, India, Philippines, South Africa, Korea
Max No. Of Connections, Access Point
7
Net Height (ERP) (mm)
93 mm
Storage Temperature °C Max
85 °C
Protection Class IP
IP65
Bluetooth Version
Classic Bluetooth v2.1
Max No. Of Connections (LE)
7
Dual Usage (ERP)
No
