CP23914N4F2C Schneider Electric Industrial Automation Components

CP23914N4F2C on Powermatic Associates
Schneider Electric

Part#:CP23914N4F2C

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Schneider Electric - CP23914N4F2C

Product Details

  • Rated Current
    400 A
  • Height
    91 in (2311.40 mm)
  • Number Of Circuits
    42
  • Range
    I-Line
  • Number Of Phases
    3 phase
  • Provided Equipment
    Neutral bar copper)
  • Width
    32 in (812.80 mm)
  • Depth
    9.5 in (241.30 mm)
  • Power Panel Type
    NF
  • Product Or Component Type
    Panelboard
  • Breaking Capacity
    10…200 kA main 18…65 kA branch
  • Rated Operational Voltage
    600Y/347 V AC 48 V DC
  • Main Type
    Main lugs Main breaker
  • Circuit Breaker Type
    HD/HG/HJ/HL LJ QD FA QJ Q4 EDB/EGB/EJB PK FC LL QB LI LA/LH LD QG LG JD/JG/JJ/JL

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of CP23914N4F2C on Powermatic Associates is $9,240.00. Order now.

CP23914N4F2C Related Documents

Product Datasheet-1631035028091.pdf
