DTU363DS Schneider Electric Industrial Automation Components

Product Details

• Duty Rating
  General duty
• Disconnect Type
  Non-fusible disconnect switch
• Number Of Poles
  3
• Net Weight
  44.09 lb(US) (20 kg)
• Product
  Double Throw Safety Switch
• Width
  11.5 in (292.10 mm)
• Current Rating
  100 A
• Depth
  7.12 in (180.85 mm)
• Height
  30.26 in (768.60 mm)
• Enclosure Rating
  NEMA 4/4X/5 stainless steel 304
• Factory Installed Neutral
  None
• Mounting Type
  Surface
• Short-Circuit Current
  10 kA H or K 200 kA R, J or T
• Fuse Type
  H or K R, J or T
• Wire Size
  AWG 12...AWG 1/0 aluminium AWG 14...AWG 1/0 copper
• Voltage Rating
  600 V AC 600 V DC
• Tightening Torque
  35 lbf.in (3.95 N.m) 0.00…0.01 in² (2.06…5.26 mm²) (AWG 14...AWG 1/0) 40 lbf.in (4.52 N.m) 0.01 in² (8.37 mm²) (AWG 8) 45 lbf.in (5.08 N.m) 0.02…0.08 in² (13.30…53.48 mm²) (AWG 8) 50 lbf.in (5.65 N.m) 0.04…0.08 in² (26.67…53.48 mm²) (AWG 6.
• Maximum Horse Power Rating
  20 hp 240 V at AC 50-60 Hz for 1 phase conforming to NEC 240.6 40 hp 240 V at AC 50-60 Hz for 3 phase conforming to NEC 430.52 40 hp 480 V at AC 50-60 Hz for 1 phase conforming to NEC 240.6 75 hp 480 V at AC 50-60 Hz for 3 phase conforming
