Part#:EDB36040

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric EDB36040 is a Miniature Circuit Breaker (MCB) designed for bolt-on mounting with a visual trip indicator. It features lugs type terminals and operates at a rated voltage of 600 V AC. This MCB is equipped with protection functions against short-circuit and overload, serving as both an Equipment Protection Device (EPD) and a Branch Circuit Breaker with a breaking capacity code D. It offers an aluminium lugs connection and supports a rated current of 40A across 3 poles. The EDB36040 accommodates a cross-section range of 12-2/0AWG and has a short circuit breaking rating of 14kA at 600Y/347Vac. Its thermal-magnetic trip unit type is set with protection settings at a trip unit rating of 1800A.

Product Details

  • Device Short Name
    EDB
  • Holding Current
    630 A
  • Trip Unit Technology
    Thermal-magnetic
  • Breaking Capacity
    14 kA 600Y/347 V AC
  • Product Destination
    NF panelboard
  • Trip Unit Rating
    1800 A
  • Number Of Spaces
    3
  • Width
    2.94 in (74.68 mm)
  • Range Of Product
    125 A Frame EDB-EGB-EJB
  • Mounting Mode
    Bolt-on
  • Number Of Poles
    3
  • Module Type
    E-Frame
  • Breaking Capacity Code
    D
  • Product Or Component Type
    Circuit-breaker
  • Circuit Breaker Application
    HACR rated
  • Height
    5.66 in (143.76 mm)
  • Net Weight
    4 lb(US) (1.81 kg)
  • Maximum Operating Voltage
    600Y/347 V AC
  • Local Signalling
    Trip indicator
  • Number Of Spaces Required
    3
  • Depth
    4.05 in (102.87 mm)
  • Line Rated Current
    40 A
  • Electrical Connection
    Lugs aluminium
  • AWG Gauge
    AWG 12...AWG 2/0 aluminium AWG 14...AWG 2/0 copper
  • Protection Type
    Short-circuit Overload
  • Tightening Torque
    34.52 lbf.in (3.9 N.m) 0.00…0.01 in² (2.5…6 mm²) (AWG 14...AWG 10) 49.56 lbf.in (5.6 N.m) 0.02…0.11 in² (10…70 mm²) (AWG 8...AWG 2/0)

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of EDB36040 on Powermatic Associates is $669.00. Order now.
