HOM1HT Schneider Electric Industrial Automation Components

HOM1HT on Powermatic Associates
Schneider Electric

Part#:HOM1HT

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric HOM1HT is a mounting accessory designed as a handle tie.

Product Details

  • Product Or Component Type
    Handle tie
  • Compatible With
    1P HOM circuit breaker
  • Rated Voltage
    120/240 V AC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of HOM1HT on Powermatic Associates is $3.50. Order now.

HOM1HT Related Documents

Product Datasheet-1631041184337.pdfInstruction Sheet-1631041184334.pdfCatalog-1631041184339.pdf
