HR2IMA24C Schneider Electric Industrial Automation Components

Name: HR2IMA24C
Brand: Schneider Electric
Price: 16170 USD
Availability: BackOrder

Part#:HR2IMA24C

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Schneider Electric - HR2IMA24C

Product Details

Width
13.46 in (341.9 mm)
Max Number Of Poles
3
Mounting Support
Panel mounting
Cable Length
19.02 in (483 mm)
Surge Current
240 kA
Breaking Capacity
100 kA
Number Of Phases
3 phase
Trip Unit Technology
Electronic
Range
Surgelogic
Wiring Configuration
4-wire
Voltage Rating
208Y/120 V AC
Rated Current
60 A
MCOV
150 V
Device Short Name
IMA
SCCR
200 kA
Type
HR
Height
12.16 in (308.9 mm)
Product
Surge protection device
Depth
5.59 in (142.1 mm)
Local Signalling
Status LED green per phase normal operation Status LED red per phase fault

Provided Equipment

Alarm enable/disable switch Surge counter Circuit breaker

Connection

I-Line line Lugs ground AWG 6 copper 35.40 lbf.in (4 N.m) Lugs neutral AWG 6 copper 35.40 lbf.in (4 N.m)

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of HR2IMA24C on Powermatic Associates is $16,170.00. Order now.

HR2IMA24C Related Documents

Instruction Sheet-1631041080155.pdf Product Datasheet-1631041080153.pdf
