LAL26400 Schneider Electric Industrial Automation Components

LAL26400 on Powermatic Associates
Schneider Electric

Part#:LAL26400

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric LAL26400 is a Moulded Case Circuit Breaker (MCCB) within the PowerPacT LAL sub-range, featuring a PowerPact LA-Frame 600 TMD 2P 400A 600Vac 22kA design. It is equipped with lugs on both load and line sides for connection, and it operates with 2 poles (2P). This MCCB offers thermal protection for overload scenarios and magnetic protection for short-circuit conditions. It has a rated current of 400A, with a rated insulation voltage (Ui) of 750 V and a rated voltage (AC) of 600Vac 600Y/347Vac. The unit is designed for individual mounting on a plate, with dimensions of 280 mm in height, 153 mm in width, and 150 mm in depth. It also has a rated voltage (DC) of 250Vdc and offers a degree of protection of IP40. The operating mode is manual toggle, with over-current protection fixed at 400A and short-circuit pickup current adjustable between 2000A and 4000A. Its rated operating voltage (Ue) is 600 V, with a rated impulse voltage (Uimp) of 8 kV. The trip current rating is 400 AT, and it has a frame current rating of 600 AF. The short circuit breaking rating varies with voltage, up to 42kA at 240Vac and down to 10kA at 250Vdc, all in accordance with UL489 standards. The trip unit type is thermal-magnetic (adjustable), without a display, and it falls under utilisation category A.

Product Details

  • Mounting Mode
    Unit mount
  • Line Rated Current
    400 A
  • Width
    6 in (152.40 mm)
  • Trip Unit Technology
    Thermal-magnetic
  • Product Or Component Type
    Circuit breaker
  • Magnetic Hold Current
    2000 A
  • Height
    11 in (279.40 mm)
  • Magnetic Tripping Current
    4000 A
  • Terminal Identifier
    AL400LA
  • Number Of Poles
    2P
  • Depth
    5.84 in (148.34 mm)
  • Tightening Torque
    115.06 lbf.in (13 N.m) 0.07…0.47 in² (42…304 mm²) (AWG 1...600 kcmil) 115.06 lbf.in (13 N.m) 0.07…0.20 in² (42…127 mm²) (AWG 1...250 kcmil)
  • Electrical Connection
    Lugs load Lugs line

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of LAL26400 on Powermatic Associates is $3,807.00. Order now.
