PK5GTA Schneider Electric Industrial Automation Components

Name: PK5GTA
Brand: Schneider Electric
Price: 11.7 USD
Availability: BackOrder

Part#:PK5GTA

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric PK5GTA is a mounting accessory designed as a back-feed retaining kit suitable for use with 150-200A electrical systems.

Product Details

Bar Length
2.24 in (57 mm)
Product Line
QO
Maximum Length Of Segment
1.26 in (32 mm)
Depth
0.312 in (7.92 mm)
Height
0.437 in (11.10 mm)
Number Of Connectors
5
Product Type
Bar
Device Mounting
Direct mounting back of enclosure
Provided Equipment
2 screw
UPC:
30785901263655
Shipping Length:
5.00 In.
Shipping Height:
1.00 In.
Shipping Weight:
0.10 lbs.
Shipping Width:
4.00 In.
Wire Size
AWG 14...AWG 4 copper AWG 12...AWG 4 aluminium
Tightening Torque
30 lb.in Mounting screw 30 lb.in 20 lb.in, AWG 14...AWG 10, copper 20 lb.in, AWG 12...AWG 10, aluminium 35 lb.in, AWG 6...AWG 4 25 lb.in, AWG 8 25 lb.in, AWG 14...AWG 12, copper 25 lb.in, AWG 12...AWG 10, aluminium

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of PK5GTA on Powermatic Associates is $11.70. Order now.

PK5GTA Related Documents

Catalog-1631030325020.pdf Instruction Sheet-1631030325031.pdf Product Datasheet-1631030325029.pdf
