2000-1403 WAGO Industrial Automation Components
Part#:2000-1403
Manufacturer:WAGO
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
2000-1403 WAGO - TOPJOB®S feedthrough terminal block; rail mount; 4-conductor; 3.5 mm wide; red
Product Details
- Weight 5.140001352 g
- Country Of Origin China
- HTS Code 85369010000
- Height 2.673 inches, 67.9 millimeters
- Insulation Material Polyamide
- Actuator Operating Tool
- Mounting Type DIN-35 Rail
- Operating Temperature 105 degrees celsius
- Color Red
- Flammability Class V0
- Package Type Box
- Conductor Material Copper
- Current 13.5 amperes, 15 amperes
- Voltage 600 volts, 800 volts
- Weight 5.140 grams
- Country of Origin China
- Width 0.138 inches, 3.5 millimeters
- Conductor Size 1.5 millimeters, 16 american wire gauge
- Strip Length 0.43 inches, 11 millimeters
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 2000-1403 on Powermatic Associates is $2.47. Order now.
About the product
Wago 2000-1403 is a feed-through terminal block featuring push-in CAGE CLAMP spring connections. It supports a variety of rated currents including 13.5A (IEC), 17.5A (IEC), 15A (UL), 10A (CSA), 13A (Ex e II), and 12A (Ex e II with jumper). This 1-deck terminal block is designed with side and center marking slots, making it suitable for Ex e II applications. It has a net height of 8 kV for impulse voltage, a net width accommodating 1 feed-through pole (1P), and is mountable on a DIN-35 rail. The terminal block is colored red, with dimensions of H67.9mm x W3.5mm x D32.9mm, and is compatible with 0.14mm2 to 1.5mm2 fine stranded or solid conductors, including #24AWG to #16AWG sizes. It has a nominal cross-section of 1mm2, is made from Polyamide (PA) 66, and includes 4-wire connections (2 push-in + 2 push-in) for enhanced connectivity. The terminal block is rated for voltages up to 800 V (IEC), 600 V (UL/CSA), and 550 V (Ex e II), and is part of the TOPJOB S series.
