281-604 WAGO Industrial Automation Components
Part#:281-604
Manufacturer:WAGO
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
281-604 WAGO - 2-conductor through terminal block; 4 mm²; suitable for Ex i applications; lateral marker slots; for DIN-rail 35 x 15 and 35 x 7.5; CAGE CLAMP®; 4,00 mm²; blue
Product Details
- Weight 6.930001823 g
- Country Of Origin Germany
- HTS Code 85369010000
- Actuator Operating Tool
- Strip Length 0.39 inches, 10 millimeters
- Country of Origin Germany
- Weight 6.930 grams
- Current 32 amperes
- Width 0.236 inches, 6 millimeters
- Conductor Material Aluminum, Copper
- Operating Temperature 105 degrees celsius
- Color Blue
- Mounting Type DIN-35 Rail
- Package Type Box
- Insulation Material Polyamide
- Conductor Size 12 american wire gauge, 4 millimeters
- Voltage 800 volts
- Flammability Class V0
- Height 2.087 inches, 53 millimeters
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 281-604 on Powermatic Associates is $2.63. Order now.
About the product
Wago 281-604 is a neutral-through terminal block designed with CAGE-CLAMP spring connections. It supports a rated current of 32A and is structured as a 1-deck/level terminal with lateral marking slots, making it suitable for Ex I applications. The terminal has a net height of 8 kV and a rated impulse voltage (Uimp) of 6 mm, with a net width designated for a neutral-through pole (N). It is designed for mounting on a DIN-35 rail (35 x 15 / 35 x 7.5) and comes in blue. The dimensions are specified as H53mm x W6mm x D29mm, accommodating cross-sections for 0.08mm2 to 4mm2 fine stranded or solid conductors and #28AWG to #12AWG fine stranded or solid conductors. The terminal block is made from Polyamide (PA) 66, features 2-wires (1 clamp + 1 clamp) (1+1) for normally closed (NC) auxiliary contacts, and is rated for a control voltage of up to 800 V.
