734-203 WAGO Industrial Automation Components

WAGO 734-203 is a connector part of the MCS - MULTI CONNECTION SYSTEM, designed without breaking capacity as per DIN EN 61984, indicating it should not be connected or disconnected under load or when live. It adheres to IEC/EN 60664-1 standards, with nominal and rated voltages of 160V and 320V under different conditions, and a rated impulse voltage of 2.5kV. The rated current is 10A. UL and CSA approvals are noted, with rated voltages of 300V and rated currents of 10A for both UL and CSA standards. It features 3 connection points, a single connection type, and one level, utilizing CAGE CLAMP technology for connection, suitable for solid and fine-stranded conductors ranging from 0.08 to 1.5mm2 (28 to 14 AWG), including those with insulated or uninsulated ferrules. The strip length for connection is 6 to 7mm. Physically, it has a pin spacing of 3.81mm, dimensions of 13.63mm in width, 13.4mm in height, and 18.6mm in depth, and includes variable coding and anti-rotation protection. The connector is a female socket type for conductor connection, made from Polyamide (PA66) in orange, with a flammability class of UL94 V0, and uses Chrome-Nickel spring steel for the clamping spring and a copper alloy with tin plating for contacts. It operates within a temperature range of -60 to +100°C, has a fire load of 0.048MJ, and weighs 2.6g. This product is RoHS compliant, packaged in boxes of 200 pieces, and is manufactured in Germany with a GTIN of 4044918494106.
