788-306 WAGO Industrial Automation Components

Wago 788-306 is a plug-in relay assembly featuring push-in CAGE CLAMP spring connections. It is designed for a rated current of 16A continuous, with specific ratings for different conditions: 6A at 250Vac (AC-15), 2A at 24Vdc (DC-13), and a 30A AC inrush maximum current. The part includes a socket base, a red LED, and an electromechanical design, recommending a minimum switching load of 12V / 1mA. It offers a 1C/O / SPDT (Single Pole Double Throw) contact resistance, with an ambient air temperature for storage ranging from -40°C to +70°C. The degree of protection is rated at IP20, with a net width of 54-66Vdc (60Vdc nominal) and a control voltage range of 0.9...1.1 x Uc. It features protection functions up to 250Vac max. (switching voltage), a control voltage (AC) of 4 kV, and is designed for a single-pole / 1-pole (1P) rated active power. The relay is suitable for DIN-35 rail mounting, has dimensions of H86mm x W15mm x D54mm with a 15mm width, and utilizes Silver-Nickel (AgNi 90/10) contacts. The rated operating voltage (Ue) supports 30,000 operations for both contacts closing and opening, with a trip current rating of 30,000,000 operations.
