SG-TL70-GYB Banner Signal Towers
Part#:SG-TL70-GYB
Alt. Part#:807001
Manufacturer:Banner
Category:Signal Towers
Product Lifecycle:Active
Jul 31, 2025
Product description
TL70 Light Module; Colors: Green Yellow Blue; Voltage: 12-30 V dc; Environmental Rating: IP65; Steady On/Flashing; Black Housing
Product Details
- Weight 95.25432 g
- Country Of Origin MX
- Feature: Quick Disconnect No
- Indication Yes
- Mounting Thread No Thread
- Animation Option 1 Dip-Switch Controlled
- Color Option 3 Blue
- Number of Colors / Segments 3
- Color Option 1 Green
- Color 3 - Wavelength/Color Temp/Coordinates 470 nm
- Primary Housing Material Polycarbonate
- Lumens Color 2 22.0
- Feature: Chemical Resistant No
- Color Input Control Individual (One wire/color, same number of colors as input wires)
- Color 1 - Wavelength/Color Temp/Coordinates 525 nm
- Physical Dimensions (LxWxH or DxH mm) 70.0 x 50.0
- Modbus RTU No
- Cable Length (m) 0.15
- Color Technology Standard LED
- Lumens Color 3 32.0
- Primary Window Material Polycarbonate Diffused
- Number of Tower Light Segments 1
- Animation Option 3 Dip-Switch Controlled
- Max Op. Temperature (°C) 50
- Power DC or AC
- Product Size (mm) 70
- Color 2 - Wavelength/Color Temp/Coordinates 590 nm
- Max Op. Relative Humidity Non-Condensing (%) 95% @ 50°C
- Storage Temp (°C) -40 to 70
- IO Link No
- Color Option 2 Yellow
- Min Op. Temperature (°C) -40
- Feature: Hazardous Area No
- Pro-Editor Compatible (Discrete) No
- Housing Style Segment - Light
- Environmental Rating IP65
- Feature: Audible No
- Wireless No
- Power Source DC or AC
- Animation Option 2 Dip-Switch Controlled
- Max Current Color (mA) 430
- Primary Housing Color Black
- Lumens Color 1 92.0
- Multi-Color Device Single Color On
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of SG-TL70-GYB on Powermatic Associates is $140.00. Order now.
About the product
Banner Engineering SG-TL70-GYB is a light unit belonging to the Modular series, featuring a 3-color G/Y/B (Green/Yellow/Blue) color pattern LED illumination designed for tow light module applications. It is constructed with polycarbonate (PC) windows and segments, along with a polycarbonate (PC) base, ensuring durability. The unit has a cylindrical shape with a diameter of 70mm / 2-3/4" and comes in a black housing. It operates on a supply voltage range of 12Vdc-30Vdc, with a nominal voltage of 24Vdc. The SG-TL70-GYB is designed to function within an ambient air temperature range of -40°C to +50°C and is rated with a degree of protection of IP65, indicating a high level of protection against dust and water ingress.
