Powermatic Associates Logo

VSM4AN6CV50 Banner Electronic Components

VSM4AN6CV50 on Powermatic Associates
Banner

Part#:VSM4AN6CV50

Manufacturer:Banner

Category:Electronic Components

Product Lifecycle:Active

Product description

VSM Series: 4 mm Smooth Barrel Diffuse, Range: 50 mm; Input 10-30 V dc, Output: 1 NPN LO (Light Operate), 2 m (6.5 ft) Cable

Product Details

  • Sensing Mode (Detailed)
    Diffuse
  • Output response time (ms)
    2.5
  • Number of Pins
    3
  • IO Link
    No
  • Cable Length (m)
    2
  • Special Feature: Remote Teach
    No
  • Adjustments
    N/A
  • Feature: Audible
    No
  • Sensing Beam
    Infrared LED
  • Max Op. Temp. (°C)
    55
  • Delay at Power-up (ms)
    20
  • Feature: Chemical Resistant
    Yes
  • Power
    DC
  • Power Supply/Supply Voltage
    10-30 V dc
  • Special Feature: Water Detection
    No
  • Opposed Mode Emitter/Receiver
    N/A
  • Primary Housing Material
    Stainless Steel
  • Operation
    Light Operate
  • Lens Material
    Sapphire
  • Feature: Hazardous Area
    No
  • Max Sensing Distance (mm)
    50
  • Quick Disconnect Type
    No QD
  • Barrel Diameter (mm)
    4
  • DeviceNet
    No
  • Housing Style
    Barrel
  • Outputs
    NPN
  • Repeatability (µs)
    1000
  • Feature: Encapsulated
    No
  • Input/Output
    Discrete
  • Special Feature: Intrinsically Safe
    No
  • Indicator
    LEDs
  • Sensing Mode (General)
    Proximity
  • Connection
    Cable
  • IP Rating
    IP67
  • Feature: Timing (Hold/Delay)
    No

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

VSM4AN6CV50 Related Documents

VSM Series Micro Sensors (Online Only)-1630949519132.pdfVSM-2 Series Micro Sensor -- Datasheet-1630949519130.pdf
