560238 Festo Pneumatic Grippers

Product Details

• Type code
  HGPT
• Design
  Inclined plane Positively driven motion sequence
• Max. operating frequency of pneumatic gripper
  ≤ 2 Hz
• Stroke per gripper jaw
  12.5 mm
• Size
  80
• Rotational symmetry
  ≤ 0.2 mm
• Mounting position
  Any
• Gripping force backup
  On opening
• Max. interchangeability
  ≤ 0.2 mm
• Pneumatic gripper repetition accuracy
  ≤ 0.05 mm
• Position sensing
  For proximity sensor
• Operating pressure
  4 bar ... 8 bar
• Degree of protection
  IP40
• Product weight
  6287 g
• Cover cap material
  High-alloy stainless steel
• Pneumatic connection
  G1/4
• Max. gripper jaw angular play ax, ay
  ≤ 0.1 deg
• Mode of operation
  Double-acting
• Operating pressure for sealing air
  0 bar ... 0.5 bar
• Operating medium
  Compressed air as per ISO 8573-1:2010 [7:4:4]
Min. closing time at 6 bar
340 ms
Maximum torque on gripper jaw, My static
220 Nm
Maximum torque on gripper jaw, Mx static
180 Nm
Housing material
Aluminum Anodized
Max. gripper jaw backlash Sz
≤ 0.02 mm
Number of gripper jaws
2
Gripper function
Parallel
Symbol
00995947
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
Maximum force on gripper jaw Fz, static
7000 N
Relubrication interval for guidance elements
5 MioCyc
Note on materials
Free of copper and PTFE RoHS-compliant
Min. opening time at 6 bar
180 ms
Mass moment of inertia
238.336 kgcm²
Max. mass per external gripper finger
1830 g
Sealing air pneumatic connection
M5
Information on operating and pilot media
Operation with oil lubrication possible (required for further use)
Ambient temperature
5 °C ... 60 °C
Maximum torque on gripper jaw, Mz static
170 Nm
Type of mounting
Optionally: With internal thread and dowel pin
Gripper jaw material
Steel Hardened
