562952 Festo Compressed Air Preparation Units
Part#:562952
Alt. Part#:MS9-EM-G-S-VS
Manufacturer:Festo
Category:Compressed Air Preparation Units
Product Lifecycle:Active
Product description
on-off valve MS9-EM-G-S-VS Manual, with silencer, direction of flow: from left to right. Series: MS, Size: 9, Grid dimension: 90 mm, Design structure: Piston slide, Type of actuation: manual
Product Details
- Width dimension 90 mm
- Actuation type Manual
- Reset method Forced guidance
- Standard nominal flow rate 18000 l/min
- Ambient temperature -10 °C ... 60 °C
- Piston slide material POM
- Housing material Die-cast aluminum
- Design Piston gate valve
- Exhaust air function Without flow control option
- Valve function 3/2, bistable
- Corrosion resistance class (CRC) 2 - Moderate corrosion stress
- Pneumatic connection 3 G1
- Product weight 2400 g
- Size 9
- Type code MS9-EM
- Symbol 00991670
- Standard nominal flow rate 2-3 14100 l/min
- Operating medium Compressed air as per ISO 8573-1:2010 [7:4:4]
- Noise level 93 dB(A)
- Actuator lock Rotary knob with detent
- Operating pressure 0 bar ... 20 bar
- Information on operating and pilot media Operation with oil lubrication possible (required for further use)
- Note on materials RoHS-compliant
- Seals material NBR
- Series MS
- Sealing principle Soft
- Type of control Direct
- Temperature of medium -10 °C ... 60 °C
- Type of mounting Optionally: With accessories
- Mounting position Any
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
562952 Related Documents
Similar products from: Festo Compressed Air Preparation Units
Manufacturer warranty
562952 Festo
Get a quick Quote!
Request a quote, and we will send you price and availability within minutes.
Select Qty:
Average response time: 11 minutes
Worldwide Shipping and Delivery
Secure Payment Processing
Warranty
Responsive Customer Support
Got Questions? We've Got Answers!
Need more details?
Feel free to chat with us
Compare 562952 with other Compressed Air Preparation Units products
Width dimension
Actuation type
Reset method
Standard nominal flow rat...
Ambient temperature
Piston slide material
Housing material
Design
Exhaust air function
Valve function
Selected product
562952
Festo
on-off valve MS9-EM-G-S-VS Manual, with silencer, direction of flow: from left to right. Series: MS,...
Width dimension90 mm
Actuation typeManual
Reset methodForced guidance
Standard nominal flow rate18000 l/min
Ambient temperature-10 °C ... 60 °C
Piston slide materialPOM
Housing materialDie-cast aluminum
DesignPiston gate valve
Exhaust air functionWithout flow control option
Valve function3/2, bistable
541282
Festo
on-off valve MS4N-EM1-1/4-S-Z Manual, with silencer, direction of flow: from right to left. Design s...
Width dimension-
Actuation typeManual
Reset method-
Standard nominal flow rate-
Ambient temperature-
Piston slide material-
Housing material-
DesignRotary gate valve
Exhaust air functionWithout flow control option
Valve function-
541267
Festo
on-off valve MS6-EM1-1/2 Manual, direction of flow: from left to right. Design structure: Rotary sli...
Width dimension-
Actuation typeManual
Reset method-
Standard nominal flow rate-
Ambient temperature-
Piston slide material-
Housing material-
DesignRotary gate valve
Exhaust air functionWithout flow control option
Valve function-
About the manufacturer
Powermatic Associates is an authorized Festo distributor, proudly offering a wide array of Festo's innovative industrial automation products and solutions. Festo is a globally recognized leader in automation technology and pneumatic solutions, renowned for their commitment to quality, efficiency, and sustainability. With a vast portfolio ranging from actuators, valves, sensors, and connectors to e...
About the Product Category
Also referred to as an FRL unit (Filter, Regulator, Lubricator), an air preparation unit is utilized to treat compressed air. It accomplishes this by eliminating impurities, managing pressure, and adding specific quantities of oil for lubrication.
