565394 Festo Flow Sensors

Product Details

• KC characters
  KC EMC
• Measured variable
  Flow rate Consumption
• Temperature of medium
  0 °C ... 50 °C
• Accuracy of flow rate
  ± (3% o.m.v. + 0.3% FS)
• Analog output
  0 - 10 V
• Short-circuit protection
  yes
• Pin allocation in accordance with standards
  EN 60947-5-2
• Mounting position
  Any
• Displayable unit(s)
  l scfm
• CE marking (see declaration of conformity)
  As per EU EMC directive As per EU RoHS directive
• Flow direction
  Unidirectional P1 -> P2
• Operating medium
  Compressed air as per ISO 8573-1:2010 [7:4:4] Nitrogen
• Repetition accuracy margin in ± %FS
  0.8 %FS
• Switching element function
  N/C contact N/O contact
• Output characteristic curve initial value
  0 V
• Min. load resistance of voltage output
  10 kOhm
• Electrical connection
  5-pin Plug, straight
• Pressure drop
  < 100 mbar
• Note on materials
  RoHS-compliant
• Flow measuring range end value
  200 l/min
Nominal temperature
23 °C
Switching function
Window comparator Threshold value comparator
End value output characteristic curve
10 V
Reverse polarity protection
for all electrical connections
Product weight
600 g
Degree of protection
IP65
Certification
RCM compliance mark c UL us - Recognized (OL)
Measuring principle
Thermal
Operating pressure
0 bar ... 10 bar
Zero point repetition accuracy in ± %FS
0.2 %FS
Switching output
2 x PNP or 2 x NPN switchable
Flow characteristic curve, start value
0 l/min
DC operating voltage range
15 V ... 30 V
Type of mounting
Optionally: With wall/surface bracket
Housing material
PA-reinforced
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
Type code
SFAB
Certificate issuing authority
UL E322346
Flow measuring range start value
2 l/min
Ambient temperature
0 °C ... 50 °C
Max. output current
≤ 100 mA
Flow characteristic curve, end value
200 l/min
Pneumatic connection
QS-8
Display type
Illuminated LCD blue
