SDR-480P-48 MEAN WELL AC/DC Power Supplies

SDR-480P-48 on Powermatic Associates
MEAN WELL

Part#:SDR-480P-48

Manufacturer:MEAN WELL

Category:AC/DC Power Supplies

Product Lifecycle:Active

Only 1 left in stock. Order Now!

Feb 23, 2026

Product description

AC-DC Industrial DIN rail power supply; Output 48Vdc at 10A; Metal casing; Ultra slim width 85.5mm; Parallel function

Product Details

  • Net weight (gram)
    1680
  • Depth (mm)
    128.5
  • Output Voltage (V)
    48
  • Height (mm)
    125.2
  • Technology
    AC/DC
  • Output Current (A)
    10
  • Dimming Technology
    No Dimming
  • Item number
    SDR-480P-48
  • Application
    Installation UL 508 ITE EN/UL/IEC 60950
  • Width (mm)
    85.5
  • IP Rating
    No IP assigned
  • Power Format
    DIN rail
  • Control Signals
    DC OK
  • Series
    SDR-480P
  • Description
    AC-DC Industrial DIN rail power supply; Output 48Vdc at 10A; Metal casing; Ultra slim width 85.5mm; Parallel function
  • Output Power (W)
    480
  • Packing quantity
    8
  • Input Voltage (V)
    110/230 universal input 90 - 264
  • RoHS
    Compliant

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

SDR-480P-48 Related Documents

Datasheet-1650344198651.pdfDrawing-1650344198642.zip
