23218CKW507 NSK Mechanical Components

Name: 23218CKW507
Brand: NSK

Part#:23218CKW507

Manufacturer:NSK

Category:Mechanical Components

Product Lifecycle:Active

Product description

Spherical Roller Bearing; 90MM Tapered Bore; 160MM Outside Diameter; 52.4MM Width; C0-Medium Clearance; Adapter Mount; Double Row of Spherical Roller Bearing; Steel Cage Material; Open Enclosure; Relubricatable

Product Details

Outside Diameter
6.299 Inch | 160 Millimeter
Bore
3.543 Inch | 90 Millimeter
Width
2.063 Inch | 52.4 Millimeter
Adapter Part Number
SNW118 H2318X HA2318X HE2318X (Specify bore) Inch | H2318X (Specify bore) Millimeter
Weight / LBS
9.82975
Inch - Metric
Metric
Other Features
Order Adapter or Withdrawal Sleeve or Nut Separately. Others May be Available | Lubrication Hole and Groove On Outer Ring | Inner Ring and Outer Ring Heat Stabilized to 200 Deg C
Withdrawal Sleeve
AHX2318 (Specify bore)
Withdrawal Nut
AN20
Relubricatable
Yes
Number of Rows of Rollers
Double Row
Enclosure
Open
Brand
NSK
Weight / Kilogram
4.46
Internal Clearance
C0-Medium
Rolling Element
Spherical Roller Bearing
Cage Material
Steel
Bore Profile
Tapered
Mounting Method
Adapter Mount
Minimum Buy Quantity
1

CATEGORY

Spherical Roller Bearings

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Manufacturer warranty

23218CKW507 NSK
