BGA34015Y Schneider Electric Industrial Automation Components

BGA34015Y on Powermatic Associates
Schneider Electric

Part#:BGA34015Y

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric BGA34015Y is a Moulded Case Circuit Breaker (MCCB) within the PowerPacT BGA sub-range, featuring a PowerPact B-Frame 100 TMD 3P 15A design for 480Y/277Vac with a 35kA I-line and 80% rated ABC phases. It has an I-line connection type, offers a degree of protection of IP40, and is rated for a current of 15A and a voltage of 480Vac 480Y/277Vac. This MCCB has a mechanical durability of 20,000 operations at no load and mounts on I-line with line side isolated plug-on jaws plus a mechanical I-Line bracket mechanism. It includes 3 poles, has dimensions of 137 mm in height, 89 mm in depth, and 81 mm in width, and falls under utilisation category A. The protection settings include over-current fixed at 15A, short-circuit hold current fixed at 400A, and short-circuit trip current fixed at 600A. It supports a rated voltage of 250Vdc, an insulation voltage of 800 V, and an operating voltage of 525 V, with thermal and magnetic protection functions. The trip current rating is 15 AT, with an electrical durability of 10,000 operations with load at 440Vac. The frame current rating is 100 AF, operated by a toggle (manual) mechanism, and has a short circuit breaking rating of 65kA at 240Vac, 35kA at 480Vac, 35kA at 480Y/277Vac, 14kA at 600Y/347Vac, and 20kA at 250Vdc, all according to UL489 standards. The trip unit type is thermal-magnetic (fixed) with no display.

Product Details

  • Breaking Capacity
    65 kA 208Y/120 V AC 50/60 Hz UL 489 65 kA 240 V AC 50/60 Hz UL 489 35 kA 480/277 V AC 50/60 Hz UL 489 35 kA 480 V AC 50/60 Hz UL 489 20 kA 250 V DC UL 489 18 kA 600Y/347 V AC 50/60 Hz UL 489
  • [Ics] Rated Service Breaking Capacity
    65 kA 220...240 V AC 50/60 Hz IEC 60947-2 18 kA 500...525 V AC 50/60 Hz IEC 60947-2 35 kA 380...415 V AC 50/60 Hz IEC 60947-2 35 kA 440 V AC 50/60 Hz IEC 60947-2
  • Number Of Slots
    1 auxiliary switch OF plug-in) 1 voltage release MN or MX plug-in) 1 alarm switch SD plug-in)
  • Tightening Torque
    31.86…38.94 lbf.in (3.6…4.4 N.m) 0.00…0.01 in² (2.5…6 mm²) (AWG 14...AWG 10) 44.25…54.87 lbf.in (5…6.2 N.m) 0.02…0.11 in² (10…70 mm²) (AWG 8...AWG 2/0)
  • Electrical Connection
    I-Line connection line Lugs load
  • Phase Connection
    ABC
  • Quantity Per Set
    Set of 1
  • 9 Mm Pitches
    9
  • Depth
    3.50 in (89 mm)
  • Width
    3.19 in (81 mm)
  • Height
    5.39 in (137 mm)
  • Power Wire Stripping Length
    0.79 in (20 mm)
  • AWG Gauge
    AWG 14...AWG 2/0 aluminium/copper
  • Mounting Mode
    I-Line
  • Utilisation Category
    Category A
  • Net Weight
    2.90 lb(US) (1.315 kg)
  • Color
    Grey (RAL 7016)
  • Connection Pitch
    1.06 in (27 mm)
  • Mounting Height
    4.49 in (114 mm)
  • Electrical Durability
    10000 cycles IEC 947-1 Annex K ed 5.2 440 V In
  • Local Signalling
    for presence of auxiliary contacts flag (green)
  • Mechanical Durability
    20000 cycles IEC 947-1 Annex K ed 5.2
  • Suitability For Isolation
    Yes IEC 60947-2
  • [Ue] Rated Operational Voltage
    525 V AC 50/60 Hz UL 489
  • [Ui] Rated Insulation Voltage
    800 V IEC 60947-2
  • Continuous Current Rating
    80 %
  • Control Type
    Toggle
  • Trip Unit Technology
    Thermal-magnetic
  • [Uimp] Rated Impulse Withstand Voltage
    8 kV IEC 60947-2
  • Breaking Capacity Code
    G
  • Line Rated Current
    15 A
  • Number Of Poles
    3P
  • Product Name
    PowerPact B
  • Product Or Component Type
    Circuit breaker
  • Device Application
    Distribution
  • Range
    PowerPact
  • Device Short Name
    BG 015

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of BGA34015Y on Powermatic Associates is $1,205.00. Order now.
