EE25S3H Schneider Electric Industrial Automation Components

EE25S3H on Powermatic Associates
Schneider Electric

Part#:EE25S3H

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Schneider Electric - EE25S3H

Product Details

  • Full Capacity Taps
    6 2.5 % 2+ 4-
  • Net Weight
    285.00 lb(US) (129.274 kg)
  • Product
    Energy Efficient Transformer
  • Secondary Voltage
    120/240 V
  • Width
    20 in (508.00 mm)
  • Temperature Rise
    150 °C
  • Phase
    1 phase
  • Insulation Temperature
    428 °F (220 °C)
  • Enclosure Code
    17H
  • Height
    37 in (939.80 mm)
  • Enclosure Type
    NEMA 2
  • Winding Material
    Aluminium
  • Power Rating
    25 kVA
  • Primary Voltage
    240 x 480 V
  • Depth
    16 in (406.40 mm)

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of EE25S3H on Powermatic Associates is $7,109.00. Order now.
