Part#:EGB36100

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric EGB36100 is a Miniature Circuit Breaker (MCB) designed for bolt-on mounting with a visual trip indicator. It features lugs type terminals and operates at a rated voltage of 600 V AC. This MCB is equipped with short-circuit and overload protection functions, serving as both an Equipment Protection Device (EPD) and a Branch Circuit Breaker with a breaking capacity code G. It offers an aluminium lugs connection and supports a rated current of 100A across 3 poles. The EGB36100 accommodates a cross-section range of 12-2/0AWG and has a short circuit breaking rating of 18kA at 600Y/347Vac. Its thermal-magnetic trip unit type is set with protection settings at a trip unit rating of 2300A.

Product Details

  • Local Signalling
    Trip indicator
  • Breaking Capacity Code
    G
  • Module Type
    E-Frame
  • Electrical Connection
    Lugs aluminium
  • Number Of Spaces Required
    3
  • Line Rated Current
    100 A
  • Number Of Spaces
    3
  • Mounting Mode
    Bolt-on
  • Depth
    4.05 in (102.87 mm)
  • Device Short Name
    EGB
  • Trip Unit Rating
    2300 A
  • Breaking Capacity
    18 kA 600Y/347 V AC
  • Height
    5.66 in (143.76 mm)
  • Range Of Product
    125 A Frame EDB-EGB-EJB
  • Number Of Poles
    3
  • Maximum Operating Voltage
    600Y/347 V AC
  • Product Destination
    NF panelboard
  • Width
    2.94 in (74.68 mm)
  • Product Or Component Type
    Circuit-breaker
  • Holding Current
    1000 A
  • Trip Unit Technology
    Thermal-magnetic
  • Circuit Breaker Application
    HACR rated
  • Net Weight
    4 lb(US) (1.81 kg)
  • AWG Gauge
    AWG 12...AWG 2/0 aluminium AWG 14...AWG 2/0 copper
  • Protection Type
    Overload Short-circuit
  • Tightening Torque
    34.52 lbf.in (3.9 N.m) 0.00…0.01 in² (2.5…6 mm²) (AWG 14...AWG 10) 49.56 lbf.in (5.6 N.m) 0.02…0.11 in² (10…70 mm²) (AWG 8...AWG 2/0)

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of EGB36100 on Powermatic Associates is $1,292.00. Order now.

EGB36100 Related Documents

Product Datasheet-1631035236608.pdfInstruction Sheet-1631035236615.pdfCatalog-1631035236613.pdf
