Part#:EGB34020CA

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

E-Frame Brkr 20A, 3P, 480Y/277V, 35/65kA, Bolt-on Mnt

Product Details

  • Range Of Product
    125 A Frame EDB-EGB-EJB
  • Holding Current
    270 A
  • Depth
    4.05 in (102.87 mm)
  • Line Rated Current
    20 A
  • Number Of Spaces Required
    3
  • Net Weight
    4 lb(US) (1.81 kg)
  • Device Short Name
    EGB
  • Breaking Capacity Code
    G
  • Maximum Operating Voltage
    480Y/277 V AC
  • Number Of Poles
    3
  • Electrical Connection
    Lugs aluminium
  • Height
    5.66 in (143.76 mm)
  • Module Type
    E-Frame
  • Number Of Spaces
    3
  • Width
    2.94 in (74.68 mm)
  • Trip Unit Rating
    875 A
  • Product Destination
    NF panelboard
  • Local Signalling
    Trip indicator
  • Product Or Component Type
    Miniature circuit-breaker
  • Mounting Mode
    Bolt-on
  • Trip Unit Technology
    Thermal-magnetic
  • Protection Type
    Overload Short-circuit
  • AWG Gauge
    AWG 12...AWG 6 aluminium AWG 14...AWG 6 copper
  • Circuit Breaker Application
    HACR rated HID rated
  • Breaking Capacity
    35 kA 277 V AC 65 kA 240 V AC 35 kA 480Y/277 V AC 65 kA 120 V AC 65 kA 120/240 V AC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
