HGF36150U33X Schneider Electric Industrial Automation Components

Out if stock but available for backorder.

Square D by Schneider Electric HGF36150U33X is a Moulded Case Circuit Breaker (MCCB) within the PowerPacT HGF sub-range, designed with a PowerPact H-Frame 150 Micrologic 3.2S (LSI) 3P 150A 600Vac/500Vdc. It features an 18kA busbar rated at 80%, with a terminal nut kit for fixed busbar connection on both line and load sides. This 3-pole (3P) device offers protection functions including Long-time (L), Short-time with fixed time delay (S), and Instantaneous (I) protection. It has a rated current of 150A, a rated insulation voltage (Ui) of 750V, and operates at rated voltages of 600Vac 600Y/347Vac and 500Vdc. The MCCB is designed for individual unit mount on plate, with dimensions of 163 mm in height, 104 mm in width, and 86 mm in depth. It provides an IP40 degree of protection and features a toggle (manual) operating mode. Protection settings are adjustable for overload (L) from 0.3 to 1 x In (50A to 150A), for short-circuit with time delay (S) from 1.5 to 10 x Ir (225A to 1500A), and for instantaneous short-circuit (I) from 1.5 to 15 x In (225A to 2250A). The rated operating voltage (Ue) is 690V, with a rated impulse voltage (Uimp) of 8kV. The trip current rating is 150 AT, with a frame current rating of 150 AF. It has a short circuit breaking rating of 65kA at 240Vac, 35kA at 480Vac and 480Y/277Vac, 18kA at 600Vac and 600Y/347Vac, and 20kA at 250Vdc and 500Vdc, according to UL489 standards. The trip unit type is an electronic Micrologic Standard 3.2S (LSI) with no display, and it falls under utilisation category A.
