HJL36090SA Schneider Electric Industrial Automation Components
Part#:HJL36090SA
Manufacturer:Schneider Electric
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
Square D by Schneider Electric HJL36090SA is a Moulded Case Circuit Breaker (MCCB) within the PowerPacT HJL sub-range. It features a factory-installed 110-130Vac shunt trip release coil, designed for PowerPact H-Frame 150 TMD, with 3 poles (3P) and a rated current of 90A. This MCCB supports a rated insulation voltage (Ui) of 750 V, with AC rated voltages of 600Vac and 600Y/347Vac, and a DC rated voltage of 250Vdc. It offers thermal protection for overload scenarios and magnetic protection for short-circuit conditions. The device is designed for individual unit mount on plate, with dimensions of 163 mm in height, 104 mm in width, and 86 mm in depth. It provides an IP40 degree of protection and operates via a toggle (manual) mechanism. Protection settings include over-current fixed at 90A, short-circuit hold current fixed at 800A, and short-circuit trip current fixed at 1450A. The rated operating voltage (Ue) is 690 V, with a rated impulse voltage (Uimp) of 8 kV. The trip current rating is 90 AT, with a frame current rating of 150 AF. Its short circuit breaking rating varies with voltage, up to 100kA at 240Vac according to UL489 standards. The trip unit type is thermal-magnetic (fixed), without a display, and it falls under utilisation category A. Connection is facilitated by lugs on both load and line sides.
Product Details
- Breaking Capacity Code J
- Tightening Torque 44.25 lbf.in (5 N.m) 0.00…0.15 in² (2.5…95 mm²) (AWG 14...AWG 3/0)
- Magnetic Hold Current 800 A
- Depth 4.36 in (110.74 mm)
- Mounting Mode Unit mount
- Range Of Product PowerPact H
- Height 6.4 in (162.56 mm)
- Line Rated Current 90 A
- Continuous Current Rating 80 %
- Magnetic Tripping Current 1450 A
- Product Or Component Type Circuit breaker
- Width 4.12 in (104.65 mm)
- Number Of Poles 3P
- Electrical Connection Lugs load Lugs line
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
