HOM2175BB Schneider Electric Industrial Automation Components

HOM2175BB on Powermatic Associates
Schneider Electric

Part#:HOM2175BB

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric HOM2175BB is a Miniature Circuit Breaker (MCB) designed for branch circuit protection. It features a plug-in connection type and is equipped with 2 poles. The rated current for this MCB is 175A, and it operates at a rated voltage of 120 V to 240 V AC. For mounting, it utilizes a plug-in mode. The HOM2175BB can accommodate a cross-section of 4AWG-300kcmil for 1 cable made of Aluminum or Copper, thanks to its box lugs terminals. It also has a short circuit breaking rating of 10kA at 120Vac.

Product Details

  • Range
    Homeline
  • Electrical Connection
    Box lugs
  • Current Rating
    175 A
  • Depth
    3.13 in (79.50 mm)
  • Short Circuit Current Rating
    10 kA
  • Wire Size
    AWG 4...300 kcmil aluminium/copper)1
  • Number Of Poles
    2P
  • Circuit Breaker Type
    Standard
  • Number Of Spaces
    4
  • Ratings
    HACR rated
  • Product
    Miniature circuit-breaker
  • Voltage Rating
    120/240 V AC
  • Width
    3.98 in (101.09 mm)
  • Mounting Type
    Plug-in
  • Height
    5.39 in (136.91 mm)
  • Certifications
    UL Listed
  • Tightening Torque
    250.48 lbf.in (28.3 N.m) 0.15…0.23 in² (95…150 mm²) (AWG 4/0...250 kcmil)

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of HOM2175BB on Powermatic Associates is $428.00. Order now.
