HOM215CAFIC Schneider Electric Industrial Automation Components

HOM215CAFIC on Powermatic Associates
Schneider Electric

Part#:HOM215CAFIC

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Schneider Electric - HOM215CAFIC

Product Details

  • Mounting Type
    Plug-in
  • Certifications
    UL Listed
  • Connections - Terminals
    Pigtail neutral
  • Voltage Rating
    120 V AC
  • Type Of Packing
    Clam packaging
  • Number Of Poles
    2P
  • Width
    2 in (50.80 mm)
  • Short Circuit Current Rating
    10 kA
  • Number Of Spaces
    2
  • Depth
    2.98 in (75.69 mm)
  • Range
    Homeline
  • Circuit Breaker Type
    Combination ARC-fault
  • Electrical Connection
    Clamp terminal for 2 cables
  • Product
    Miniature circuit-breaker
  • Current Rating
    15 A
  • Height
    3.13 in (79.50 mm)
  • Ratings
    HACR rated
  • Tightening Torque
    35.40 lbf.in (4.0 N.m) 0.00…0.02 in² (2.5…10 mm²) (AWG 16...AWG 14) 35.40 lbf.in (4.0 N.m) 0.01…0.03 in² (4…20 mm²) (AWG 12...AWG 4)
  • Wire Size
    AWG 14...AWG 8 aluminium/copper)1 AWG 14...AWG 10 copper)2

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
