HOMT2020CP Schneider Electric Industrial Automation Components

HOMT2020CP on Powermatic Associates
Schneider Electric

Part#:HOMT2020CP

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Schneider Electric - HOMT2020CP

Product Details

  • Depth
    2.98 in (75.69 mm)
  • Width
    1 in (25.40 mm)
  • Height
    3.13 in (79.50 mm)
  • Tightening Torque
    35.40 lbf.in (4.0 N.m) 0.00…0.01 in² (2.5…6 mm²) (AWG 14...AWG 8)
  • Type Of Packing
    Consumer packaging
  • Wire Size
    AWG 14...AWG 8 aluminium/copper)1
  • Electrical Connection
    Box lugs
  • Ratings
    HACR rated
  • Circuit Breaker Type
    Tandem
  • Number Of Poles
    1P
  • Certifications
    UL Listed
  • Short Circuit Current Rating
    10 kA
  • Number Of Spaces
    1
  • Product
    Miniature circuit-breaker
  • Range
    Homeline
  • Mounting Type
    Plug-in
  • Current Rating
    20 A
  • Voltage Rating
    120/240 V AC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
