QO1515 Schneider Electric Industrial Automation Components

QO1515 on Powermatic Associates
Schneider Electric

Part#:QO1515

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric QO1515 is a tandem miniature circuit breaker (MCB) designed for plug-in mounting. It features a rated current of 15A/15A and accommodates a plug-in connection type. This MCB operates at a rated voltage of 120 V to 240 V and is compatible with a cross-section of 14-8AWG for 1 cable Al/Cu. It is a single-pole device with a short circuit breaking rating of 10kA at 240Vac. The QO1515 is equipped with box lug type terminals.

Product Details

  • Depth
    2.91 in (73.91 mm)
  • Product
    Miniature circuit-breaker
  • Number Of Poles
    1P
  • Tightening Torque
    40.71 lbf.in (4.6 N.m)
  • Ratings
    HACR rated
  • Interrupt Rating
    10 kA 120/240 V AC 50/60 Hz
  • Mounting Type
    Plug-in
  • Number Of Panel Spaces
    1
  • Circuit Breaker Type
    Tandem
  • Width
    0.75 in (19.05 mm)
  • Range
    QO
  • Wire Size
    AWG 14...AWG 8 copper or aluminium
  • Height
    3.22 in (81.79 mm)
  • Current Rating
    15 A
  • Voltage Rating
    120/240 V AC
  • Electrical Connection
    Box lugs
  • Shipping Width:
    4.00 In.
  • TS PIK:
    21032739
  • UPC:
    78590140090
  • Shipping Weight:
    3.40 lbs.
  • Shipping Height:
    4.00 In.
  • Shipping Length:
    8.00 In.

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of QO1515 on Powermatic Associates is $73.00. Order now.

QO1515 Related Documents

Instruction Sheet-1631030911597.pdfCatalog-1631030911602.pdfProduct Datasheet-1631030911595.pdf
