QOU230H5283 Schneider Electric Industrial Automation Components

QOU230H5283 on Powermatic Associates
Schneider Electric

Part#:QOU230H5283

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric QOU230H5283 is a unit-mount Miniature Circuit Breaker (MCB) designed for securing electrical circuits. It features a 2-pole configuration and is capable of handling a rated current of 30A. This MCB is equipped with ring tongue connections on both the load and line sides, facilitating secure and straightforward installation. It operates at a rated voltage of 240V AC and offers a short circuit breaking rating of 10kA at 240V AC and 5kA at 48V DC. The terminals are designed to accommodate ring tongue connectors, ensuring a reliable connection.

Product Details

  • AWG Gauge
    AWG 14...AWG 2 aluminium/copper
  • Mounting Mode
    Unit mount
  • Height
    4.05 in (102.87 mm)
  • Circuit Breaker Application
    HACR and Switching Duty rated
  • Tightening Torque
    45 lbf.in (5.08 N.m) (AWG 14...AWG 2)
  • Line Rated Current
    30 A
  • Width
    1.5 in (38.10 mm)
  • Circuit Breaker Type
    Standard
  • Range Of Product
    QOU
  • Product Or Component Type
    Miniature circuit-breaker
  • [Ue] Rated Operational Voltage
    240 V AC
  • Depth
    2.95 in (74.93 mm)
  • Electrical Connection
    ring tongue, line side ring tongue, load side

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of QOU230H5283 on Powermatic Associates is $252.00. Order now.
