S33682 Schneider Electric Industrial Automation Components

S33682 on Powermatic Associates
Schneider Electric

Part#:S33682

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Schneider Electric - S33682

Product Details

  • Rated Voltage
    200…240 V AC/DC
  • Accessory / Separate Part Category
    Trip unit accessory
  • Product Or Component Type
    Time delay switch
  • Circuit Breaker Type
    R-Frame NW P-frame J-frame M-frame H-frame L-Frame NT
  • Range Of Product
    PowerPact L PowerPact R PowerPact P PowerPact J PowerPact H PowerPact M Masterpact NT Masterpact NW
  • Product Compatibility
    PowerPact R PowerPact PowerPact H PowerPact H-Frame PowerPact J PowerPact J-Frame PowerPact L PowerPact L-Frame Masterpact NT Masterpact Masterpact NW Masterpact Masterpact Masterpact PowerPact PowerPact PowerPact P

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of S33682 on Powermatic Associates is $1,140.00. Order now.

S33682 Related Documents

Catalog-1631033186275.pdfProduct Datasheet-1631033186258.pdf
