Powermatic Associates Logo

NI3-EG08-AP6X-V1131 Turck Industrial Automation Components

NI3-EG08-AP6X-V1131 on Powermatic Associates
Turck

Part#:NI3-EG08-AP6X-V1131

Alt. Part#:4602750

Manufacturer:Turck

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

NI3-EG08-AP6X-V1131 Turck - NI3-EG08-AP6X-V1131 Inductive Sensor

Product Details

  • Weight
    19 g
  • RoHS
    Yes
  • Country Of Origin
    LKA
  • HTS Code
    8536507000
  • Construction size
    M8 x 1
  • Design
    Threaded barrel
  • Electrical connection
    Connector, M8 × 1
  • Mounting
    Non-flush
  • Housing material
    Stainless steel, 1.4305 (AISI 303)
  • Operating voltage
    10…30 VDC
  • Output function
    NO contact, PNP
  • Protection class
    IP67
  • Rated switching distance
    3 mm
  • Ambient temperature
    -25…+70 °C
  • Ambient Temperature
    -25 degrees celsius, 70 degrees celsius
  • Country of Origin
    Sri Lanka
  • Operating Voltage
    10 volts, 30 volts
  • Weight
    19 grams

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of NI3-EG08-AP6X-V1131 on Powermatic Associates is $145.20. Order now.

About the product

Inductive Sensor, Rated switching distance 3 mm, Non-flush, M8 × 1 threaded barrel, Stainless steel, 1.4305 (AISI 303), DC 3-wire, 10…30 VDC, NO contact, PNP output, M8 x 1 male connector

NI3-EG08-AP6X-V1131 Related Documents

English-1630964993298.pdf
