2059-901/021-000 WAGO Electrical Connector Accessories
Part#:2059-901/021-000
Manufacturer:WAGO
Category:Electrical Connector Accessories
Product Lifecycle:Active
Product description
2059-901/021-000 WAGO - Board-to-Board Link; Pin spacing 3 mm; 1-pole; Length: 20.5 mm; white
Product Details
- Weight 0.083000022 g
- Country Of Origin China
- HTS Code 85369010000
- Current 3 amperes
- Color White
- Weight 0.083 grams
- Country of Origin China
- Width 0.106 inches, 2.7 millimeters
- Height 0.098 inches, 2.5 millimeters
- Contact Type Silver
- Flammability Class V0
- Package Type Box
- Depth 0.807 inches, 20.5 millimeters
- Contact Material Copper Alloy
- Voltage 63 volts
- Insulation Material Polyamide
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 2059-901/021-000 on Powermatic Associates is $0.26. Order now.
About the product
WAGO 2059-901/021-000 is an SMD PCB terminal block designed for a single potential connection with a pole number of 1. It features a nominal voltage of 63V (III/3), 160V (III/2), and 320V (II/2), with a rated impulse voltage of 2.5kV for all categories and a rated current of 3A. The part has a pin spacing of 3mm, dimensions of 2.7mm in width, 2.5mm in height, and 20.5mm in depth, and supports up to 10 mating cycles. It is suitable for use with the 2059 Series SMD PCB terminal blocks. The terminal block is made from white polyamide (PA66) with a flammability class of V0, copper alloy contacts, and silver plating. It has a fire load of 0.001MJ and weighs 0.1g. This part operates within a temperature range of -60 to +105°C, is RoHS compliant without exemptions, and comes in a box packaging of 1500 pieces per unit. The product's country of origin is China, with a GTIN of 4055143610049 and a customs tariff number of 85369010000.
