812-114 WAGO Industrial Automation Components
Part#:812-114
Manufacturer:WAGO
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
812-114 WAGO - Busbar terminal block; for (10 x 3) mm busbars; without push-buttons; CAGE CLAMP®; 16,00 mm²; blue
Product Details
- Weight 42.90001128 g
- Country Of Origin Poland
- HTS Code 85369010000
- Actuator Operating Tool
- Conductor Material Copper
- Strip Length 0.47 inches, 12 millimeters
- Color Blue
- Conductor Size 16 millimeters, 6 american wire gauge
- Package Type Box
- Height 1.673 inches, 42.5 millimeters
- Flammability Class V0
- Operating Temperature 85 degrees celsius
- Depth 1.713 inches, 43.5 millimeters
- Width 1.496 inches, 38 millimeters
- Insulation Material Polyamide
- Country of Origin Poland
- Voltage 1000 volts
- Current 96 amperes
- Weight 42.900 grams
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 812-114 on Powermatic Associates is $9.77. Order now.
About the product
Wago 812-114 is a terminal strip designed for efficient electrical connections, featuring CAGE-CLAMP spring connections for secure and maintenance-free operation. It supports a rated current of 96A according to IEC standards and is built as a 1-deck/level design. This terminal strip is capable of mounting on a 10x3mm copper bar and is suitable for 1.5mm2 to 16mm2 fine stranded or solid conductors, as well as #14AWG to #6AWG fine stranded or solid conductors. The product is made from Polyamide (PA) 66, ensuring durability and stability under electrical loads. It has a net height of 6 kV, with dimensions specified as H42.5mm x W38mm x D43.5mm, and is designed to work with 3-wires (3 clamps) connections. The terminal strip is rated for a control voltage of 1000 V according to IEC standards, indicating its capability to handle high-voltage applications.
