883-1230 WAGO Industrial Automation Components
Part#:883-1230
Manufacturer:WAGO
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
883-1230 WAGO - Power tap; 10,00 mm²; beige
Product Details
- Operating Temperature 105 degrees celsius
- Package Type Bag
- Insulation Material Polyamide
- Actuator Slot Screwdriver; (4 X 0.8) Mm Blade
- Voltage 1000 volts
- Conductor Size 10 millimeters, 8 american wire gauge
- Weight 12.610 grams
- Current 57 amperes
- Strip Length 0.47 inches, 12 millimeters
- Country of Origin Germany
- Color Beige
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 883-1230 on Powermatic Associates is $11.79. Order now.
About the product
WAGO 883-1230 is a screw connection terminal block designed for a nominal voltage of 1000V (III/3), with a rated impulse voltage of 6kV (III/3) and a rated current of 57A. It features a single connection point on the side, utilizing a screw connection technology that is actuated with a slot screwdriver (4 x 0.8)mm blade. The terminal block accommodates a nominal cross-section of 10mm2 and is compatible with solid, stranded, and fine-stranded conductors ranging from 0.2 to 10mm2 (22 to 8 AWG), including fine-stranded conductors with insulated ferrules. The recommended strip length for wire preparation is 12mm / 0.47". It requires a tightening torque between 1.2 and 2Nm. The terminal block is beige, made from Polyamide (PA66) with a flammability class of V2 according to UL94, and weighs 12.6g. It is designed to operate continuously within a temperature range of -35 to +105°C. This product is RoHS compliant without exemptions, packaged in bags of 10 pieces, and has a GTIN of 4055143940283. The country of origin is Germany, and it has a customs tariff number of 85366990990.
