Part#:B-TL70Z-Q5C

Manufacturer:Banner

Category:Electronic Components

Product Lifecycle:Active

Product description

Banner Engineering B-TL70Z-Q5C is a base unit belonging to the Modular series, designed as a base segment or module with a gray polycarbonate housing. It supports 1-4 modules within its cylindrical shape, measuring 70mm or approximately 2-3/4" in diameter. This unit is pre-equipped with a 5-pin M12 Euro-style quick disconnect (QD) connector and operates on a supply voltage ranging from 100Vac to 240Vac, including 120Vac, 220Vac, and 230Vac options. It features 4 digital inputs for color control, each requiring 100-240Vac, and has a current consumption of 420mA. The B-TL70Z-Q5C is designed for surface or base pole mounting with an M30 thread and offers a degree of protection rated at IP65, making it suitable for operation in ambient air temperatures ranging from -40°C to +50°C.

Product Details

  • Housing Style
    Segment - Base
  • Number of Input Pins/Conductors
    5
  • Max Op. Relative Humidity Non-Condensing (%)
    95% @ 50°C
  • Wireless
    No
  • Power
    AC
  • Color Technology
    Standard LED
  • Environmental Rating
    IP65
  • Feature: Quick Disconnect
    Yes
  • Indication
    Yes
  • Supply Voltage
    100-240 V ac
  • Feature: Audible
    No
  • Mounting Thread
    M30 x 1.5
  • Input Type
    AC
  • Storage Temp (°C)
    -40 to 70
  • Primary Housing Material
    Polycarbonate
  • Max Op. Temperature (°C)
    50
  • Modbus RTU
    No
  • Min Op. Temperature (°C)
    -40
  • Pro-Editor Compatible (Discrete)
    No
  • Power Source
    AC
  • Product Size (mm)
    70
  • Feature: Hazardous Area
    No
  • Non-Illuminated
    Yes
  • Max Input Response Time (ms)
    240
  • Feature: Chemical Resistant
    No
  • Color Input Control
    Individual (One wire/color, same number of colors as input wires)
  • Connection
    Integral QD
  • Physical Dimensions (LxWxH or DxH mm)
    70.0 x 115.8
  • IO Link
    No
  • Number of Colors / Segments
    1
  • Primary Housing Color
    Gray

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
