PIA46UHFM15X7 Banner Through Beam Sensors

Name: PIA46UHFM15X7
Brand: Banner
Price: 196 USD
Availability: BackOrder

Part#:PIA46UHFM15X7

Alt. Part#:81831

Manufacturer:Banner

Category:Through Beam Sensors

Product Lifecycle:Active

Product description

Plastic Fiber, Opposed Mode; Core Dia.: 1 mm; Fiber Length 2 m; Angle; DuraBend, Free cut

Product Details

Weight
90.7184 g
Country Of Origin
JP
Max Distance: DF-G1 (mm)
No Data
Max Distance: DF-G2 (mm)
No Data
Tariff Fiber Meters (fbm)
4
Measured Max Distance (mm)
No Data
Application: Vacuum Feed Through
None
Termination Type
Plastic Fiber Sensors
Application: Liquid Level
No
Feature: Small Object Detection
No
Feature: Chemical Resistant
No
Minimum Repeat Bending Endurance
1000
Termination
Free Cut
Minimum Bend Radius (mm)
2
Core Diameter (mm)
1
Flex Relief
No
Retractile
No
Sensing End Segment 1
Rectangle
Max Distance: DF-G3 (mm)
No Data
Fiber Sensing End Size - Mounting Area
15.0 x 7.0 mm

Feature: Extended Range

Integrated Lens

Max Temp ( °C)

Sensing End Segment 2

Sideview

Fiber Length (m)

Fiber Sensing End Size

15.0 x 7.0 mm

Fiber Sheathing Material (Jacket)

Polyethylene

Beam Exit

Right Angle

Fiber Sensing End Tip

Sideview

Sensing End Material (Specific)

Stainless Steel

Sensing Mode (Detailed)

Reflective

Sensing Mode (General)

Opposed

Quantity Included

Fiber Optic Type

Plastic

Housing Style

Rectangular

Sub-range name

Plastic fiber series

Functions

Fiber optic sensor

Ambient air temperature for operation

+70 °C

Main function

Fiber sensor

Length

6ft / 2m

Material

Plastic fiber Plastic fiber Polyethylene fiber sheath

Product series / family name

Fiber sensors

Dimensions

15x7mm sensing area

Primary brand

Banner Engineering

Diameter

1mm fiber core

Order code / Manufacturer SKU

81831

Design

through-beam system / opposed mode pair of individual fibers Side / right-angled sensing

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of PIA46UHFM15X7 on Powermatic Associates is $196.00. Order now.

About the product

Banner Engineering PIA46UHFM15X7 is a fiber optic sensor designed for precise detection tasks. It operates within an ambient air temperature up to +70°C and features a through-beam system, also known as an opposed mode pair of individual fibers positioned side by side with right-angled sensing. The sensor has a 1mm fiber core diameter and belongs to the Plastic fiber series. It offers an 8x12mm rectangular sensing area. The construction includes a plastic sensing end and a polyethylene (PE) fiber sheath, ensuring durability and compatibility with various applications. The total length of the fiber is 6ft (2m), facilitating flexible installation options.

PIA46UHFM15X7 Related Documents

PIA4 SERIES HIGH FLEX UNTERMINATED-1630955193918.pdf PIA4 SERIES HIGH FLEX UNTERMINATED-1630955193911.stp
