PIF630UM.78M.16D Banner Electronic Components

Product Details

• Product series / family name
  Fiber sensors
• Diameter
  1.5mm fiber core
• Material
  Stainless steel sensing end Plastic fiber Polyethylene fiber sheath
• Primary brand
  Banner Engineering
• Functions
  Fiber optic sensor
• Sub-range name
  Plastic fiber series
• Length
  30ft / 10m
• Order code / Manufacturer SKU
  803792
• Design
  through-beam system / opposed mode pair of individual fibers In-line sensing
• Ambient air temperature for operation
  +70 °C
• Main function
  Fiber sensor
• Shape
  Cylindrical (threaded) end tip
• Dimensions
  4x19.8mm sensing area
• Beam Exit
  In-line
• Sensing End Segment 1
  Ferrule
• Feature: Small Object Detection
  No
• Sensing Mode (Detailed)
  Reflective
• Minimum Bend Radius (mm)
  40
• Measured Max Distance (mm)
  No Data
• Housing Style
  Round
Flex Relief
No
Integrated Lens
No
Fiber Sensing End Size - Mounting Area
4.0 mm
Fiber Length (m)
10
Quantity Included
2
Termination
Free Cut
Fiber Sensing End Tip
Ferrule
Minimum Repeat Bending Endurance
10000
Tariff Fiber Meters (fbm)
20
Fiber Sensing End Size
4.0 mm
Application: Vacuum Feed Through
None
Max Distance: DF-G3 (mm)
No Data
Sensing End Material (Specific)
Stainless Steel
Application: Liquid Level
No
Max Distance: DF-G1 (mm)
No Data
Fiber Optic Type
Plastic
Max Temp ( °C)
70
Max Distance: DF-G2 (mm)
No Data
Fiber Sheathing Material (Jacket)
Polyethylene
Core Diameter (mm)
1.5
Feature: Extended Range
No
Sensing Mode (General)
Opposed
Retractile
No
Feature: Chemical Resistant
No
Termination Type
Plastic Fiber Sensors
