PIR1X323T-VL Banner Through Beam Sensors
Part#:PIR1X323T-VL
Alt. Part#:87529
Manufacturer:Banner
Category:Through Beam Sensors
Product Lifecycle:Active
Product description
Plastic Fiber, Opposed Mode; Core Dia.: 32 x 0.25 mm; Fiber Length 1 m; Rectangle W/Flex Relief; Vantage Line Terminated for use in Plastic Fiber Sensors
Product Details
- Weight 26.0361808 g
- Country Of Origin TW
- Design through-beam system / opposed mode flex strain relief pair of individual fibers In-line sensing
- Diameter 0.25mm fiber core
- Product series / family name Fiber sensors
- Length 3ft / 1m
- Shape Rectangular
- Primary brand Banner Engineering
- Functions Fiber optic sensor
- Equivalent to PIR1X323TVL
- Main function Fiber sensor
- Material Plastic sensing end Plastic fiber Polyethylene fiber sheath
- Order code / Manufacturer SKU 87529
- Sub-range name Plastic fiber - Vantage Line
- Dimensions 25x19mm sensing area
- Ambient air temperature for operation +70 °C
- Fiber Optic Type Plastic
- Array Length (mm) 14.5
- Minimum Repeat Bending Endurance 1000
- Quantity Included 2
- Sensing Mode (Detailed) Array
- Fiber Length (m) 1
- Fiber Sheathing Material (Jacket) Polyethylene
- Beam Exit In-line
- Retractile No
- Feature: Chemical Resistant No
- Max Distance: DF-G3 (mm) 5161
- Application: Vacuum Feed Through None
- Sensing End Material (Specific) Polyethylene
- Fiber Sensing End Size 19.0 x 25.0 mm
- Feature: Extended Range No
- Fiber Sensing End Size - Mounting Area 19.0 x 25.0 mm
- Housing Style Rectangular
- Flex Relief Yes
- Feature: Small Object Detection No
- Sensing Mode (General) Opposed
- Fiber Sensing End Tip Array
- Minimum Bend Radius (mm) 60
- Termination Type Plastic Fiber Sensors
- Sensing End Segment 1 Rectangle
- Integrated Lens No
- Measured Max Distance (mm) 664
- Max Range: DF-G3 (mm) >5m
- Max Temp ( °C) 70
- Tariff Fiber Meters (fbm) 64
- Max Distance: DF-G1 (mm) 664
- Termination Terminated
- Max Distance: DF-G2 (mm) 1076
- Sensing End Segment 2 Array
- Core Diameter (mm) 32 x 0.3
- Application: Liquid Level No
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of PIR1X323T-VL on Powermatic Associates is $160.00. Order now.
About the product
PULS PIR1X323T-VL is a redundancy unit featuring dual-input redundancy module capabilities with 2 x inputs and 1 x output, designed for DIN rail mounting. It operates within an ambient air temperature range of -40 to +70°C and utilizes diode technology. The unit is rated for a current of 20A at 28Vdc, with a derating to 0.5A between +55°C and +70°C. It offers screw-clamp connections for secure installation and measures W39mm x H124mm x D124mm. The supply voltage range is 9Vdc-35Vdc, supporting nominal 12Vdc and 24Vdc systems, while the output voltage range is 12-28Vdc. Constructed with a polycarbonate (PC) housing, it provides short-circuit protection with a 26A threshold at 6V. The unit supports series/parallel operation for 1+1 redundancy and N+1 redundancy, allowing for parallel connection of two or more identical power supplies to ensure continuous operation in case of a single power supply failure. It features a peak inrush current of 42A at 230Vac input and 18A at 120Vac input, with power dissipation/losses at nominal load of 11.2W. Electrical durability is rated at 113,000 hours at 40°C for N+1 redundancy with 2x10A, and up to 874,000 hours at 25°C for 1+1 redundancy with 2x5A. The unit exhibits a ripple of 460mVpp across a frequency range of 20Hz to 20MHz at 50Ω.
