PVA225P6R Banner Optical Sensors
Part#:PVA225P6R
Alt. Part#:50789
Manufacturer:Banner
Category:Optical Sensors
Product Lifecycle:Active
Product description
PVA Series: 225 mm Array - Receiver; Range: 2 m; Input: 12-30 V dc; Output: 1 PNP Programmable for LO/DO; 2 m (6.5 ft) Integral Cable
Product Details
- Weight 278.95908 g
- Country Of Origin MX
- Power Source DC
- Input Type Bimodal (PNP/NPN)
- Number of Input Pins/Conductors 4
- Max Op. Temperature (°C) 50
- Modbus RTU No
- Cable Length (m) 2
- Color Option 1 Green
- Number of Colors / Segments 1
- Beam Spacing (mm) 25.0
- Feature: Hazardous Area No
- Housing Style Flat Mount - Array
- Max Current Color (mA) 62
- Output Type PNP
- NEMA Type and UL Type Rating NEMA 2
- IO Link No
- Sensing Mode (Detailed) Receiver
- Animation Option 1 Dip-Switch Controlled
- Environmental Rating IP62
- Max Output Response Time (ms) 40
- Pro-Editor Compatible (Discrete) No
- Activation Function Optical
- Product Size (mm) Other
- Physical Dimensions (LxWxH or DxH mm) 266.4 x 30.0 x 15.0
- Primary Window Material Acrylic Clear
- Job Light Green
- Sensing Mode (General) Opposed
- Mounting Thread No Thread
- Supply Voltage 12-30 V dc
- Feature: Audible No
- Number of Beams 10
- Power DC
- Color Input Control Individual (One wire/color, same number of colors as input wires)
- Color Technology Standard LED
- Sensing Array Length (mm) 225
- Sensing Resolution (mm) 35.0
- Primary Housing Material Aluminum
- Operation Normally Open/Normally Closed
- Array Length (mm) 225.0
- Primary Housing Color Black
- Feature: Chemical Resistant No
- Actuation Yes
- Connection Cable
- Maximum Sensing Distance (mm) 2000
- Button Operation Momentary
- Wireless No
- Feature: Quick Disconnect No
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of PVA225P6R on Powermatic Associates is $456.00. Order now.
About the product
Banner Engineering PVA225P6R is a photo-electric array sensor designed for a variety of applications requiring precise detection. This sensor features an emitter and receiver pair with a sensing distance of up to 2 meters and operates within an ambient air temperature of up to +50°C. It comes in a rectangular shape with dimensions of 225mm in array length, 30mm in width, and 267mm in depth, and is constructed with an aluminium housing and an acrylic window for durability. The PVA225P6R is equipped with a pre-wired 2m pigtail terminated with a 4-pin M12 connector for easy installation and has a net height of 15mm. It offers a supply voltage range of 12Vdc to 30Vdc, with 24Vdc as the nominal voltage, and consumes 62mA of current. The sensor provides a degree of protection of IP62 NEMA 2 and features a green light color with a 25mm beam spacing/pitch. Its operating modes include Light-ON, Dark-ON, Normally Open (NO), and Normally Closed (NC), along with 1 x digital output (PNP transistor) for versatile application use.
