QMT42VN6FF1500 Banner Optical Sensors

QMT42VN6FF1500 on Powermatic Associates
Banner

Part#:QMT42VN6FF1500

Alt. Part#:57543

Manufacturer:Banner

Category:Optical Sensors

Product Lifecycle:Active

Product description

QMT42 Series: Fixed Field; Range: 1500 mm; Input: 10-30 V dc; Output: SPDT (Complementary) NPN; 2 m (6.5 ft) Cable

Product Details

  • Weight
    235.86784 g
  • Country Of Origin
    CN
  • Primary brand
    Banner Engineering
  • Functions
    Fixed-field photo-electric sensor green LED (power ON) amber LED (light sensed)
  • Response time
    1ms / 0.001 s
  • Ambient air temperature for operation
    -20...+55 °C
  • Sensing distance
    1.5m
  • Operating mode
    Light-ON Dark-ON
  • Main function
    Sensor (Photo-electric)
  • Supply voltage (DC)
    10Vdc-30Vdc (12Vdc / 24Vdc nom.)
  • Light Color
    Infrared (IR)
  • Degree of protection
    IP67 NEMA 6
  • Compliant with standard(s)
    cURus CE
  • Product series / family name
    Q series
  • Design
    background suppression system
  • Shape
    Rectangular
  • Connection type
    Pre-wired with 6.5ft / 2m cable terminated with bare end flying leads
  • Sub-range name
    QMT42
  • Wavelength
    880 nm
  • Digital outputs
    1 x digital output (NPN transistor)
  • Order code / Manufacturer SKU
    57543
  • Material
    Die-cast Zinc alloy housing Acrylic lns.
  • Repeatability (µs)
    250
  • Feature: Timing (Hold/Delay)
    No
  • Sensing Beam Wavelength
    880
  • Adjustments
    N/A
  • Feature: Audible
    No
  • Operation
    Light/Dark Operate
  • IP Rating
    IP67
  • Feature: Encapsulated
    No
  • Power
    DC
  • Quick Disconnect Type
    No QD
  • Special Feature: Remote Teach
    No
  • Lens Material
    Acrylic
  • Connection
    Cable
  • Number of Pins
    4
  • IO Link
    No
  • Output response time (ms)
    1
  • Feature: Hazardous Area
    No
  • Min Op. Temp. (°C)
    -20
  • Barrel Diameter (mm)
    N/A
  • Feature: Chemical Resistant
    No
  • Delay at Power-up (ms)
    100
  • Opposed Mode Emitter/Receiver
    N/A
  • Max Op. Relative Humidity [%]
    90% @ 50°C
  • Housing Style
    Rectangular
  • Sensing Beam
    Infrared LED
  • Input/Output
    Discrete
  • Max Sensing Distance (mm)
    1500
  • Max Op. Temp. (°C)
    55
  • Sensing Mode (General)
    Proximity
  • Special Feature: Intrinsically Safe
    No
  • NEMA Rating
    NEMA 6
  • Primary Housing Material
    Zinc Alloy Die-Cast
  • Sensing Mode (Detailed)
    Background Suppression (Fixed)
  • Cable Length (m)
    2
  • Power Supply/Supply Voltage
    10-30 V dc
  • Outputs
    NPN
  • Special Feature: Water Detection
    No
  • Indicator
    LEDs
  • DeviceNet
    No

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of QMT42VN6FF1500 on Powermatic Associates is $266.00. Order now.

About the product

Banner Engineering QMT42VN6FF1500 is a fixed-field photo-electric sensor designed with a background suppression system. It operates within an ambient air temperature range of -20 to +55 °C and is housed in a die-cast Zinc alloy with an Acrylic lens, ensuring durability. This sensor is pre-wired with a 6.5ft / 2m cable that terminates with bare end flying leads for easy installation. Part of the QMT42 series, it offers a degree of protection rated at IP67 NEMA 6, making it suitable for challenging environments. The sensor operates on a supply voltage of 10Vdc to 30Vdc, with nominal voltages of 12Vdc and 24Vdc. Its rectangular shape is designed for straightforward mounting, and it can detect objects up to 1.5m away using infrared light with a wavelength of 880 nm. The QMT42VN6FF1500 features a digital output (NPN transistor; complementary NO/NC) and supports both Light-ON and Dark-ON operating modes, with a rapid response time of 1ms / 0.001 s.
