RP-RM83F-38LTE Banner Safety Switches

RP-RM83F-38LTE on Powermatic Associates
Banner

Part#:RP-RM83F-38LTE

Alt. Part#:82126

Manufacturer:Banner

Category:Safety Switches

Product Lifecycle:Active

Product description

Heavy-Duty Metal Emergency Stop Rope Pull; Turnbuckle Attachment, 38 m Max Range, Integral E-Stop Button; Latch Actuation, 2 NC Safety Contacts; 2 NO Aux Contacts, PNP Aux Output

Product Details

  • Weight
    1043.2616 g
  • Country Of Origin
    DE
  • Dimensions (HxWxD mm )
    282 x 90 x 88
  • Primary Housing Material
    Aluminum Alloy Die-Cast
  • Feature: Lockable
    No
  • Max Operating Temperature ( °C)
    80
  • Button Diameter (mm)
    33
  • Actuator/Button Material
    Zinc Alloy Die-Cast
  • Contact Quantity
    2 NO, 2 NC
  • Min Operating Temperature ( °C)
    -30
  • Contact Rating
    10 A @ 110 V ac; 6 A @ 24 V dc
  • Max Cable Length (m)
    37.5
  • Button Shroud
    No
  • Device Type
    Rope Pull w/E-Stop Button
  • Actuation
    Latch
  • Housing Style
    Limit Switch
  • Attachment
    Tunbuckle
  • IP Rating
    IP67
  • Connection Type
    Wiring Chamber

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of RP-RM83F-38LTE on Powermatic Associates is $295.00. Order now.

About the product

Banner Engineering RP-RM83F-38LTE is a heavy-duty rope-pull/grab-wire emergency stop switch designed for industrial safety applications. This part of the RP-RM83F series features a die-cast Aluminium alloy housing and die-cast Zinc alloy actuator, ensuring durability in challenging environments. It is equipped with an emergency stop button, a turnbuckle for rope tension adjustment, and an auxiliary status output for enhanced functionality. The switch offers a wiring chamber connection type and can accommodate a maximum rope span of 37.5 meters. It includes 2NC (safety) + 2NO (auxiliary) contacts, supporting a supply voltage range of 24Vac-230Vac (with 120Vac and 220Vac nominal) and 24Vdc. The rated current specifications are 6A at 120Vac (AC-15; 40-60Hz), 0.55A at 120Vdc (DC-13), 3A at 240Vac (AC-15; 40-60Hz), and 0.27A at 240Vdc (DC-13). This switch operates within an ambient air temperature range of -30 to +80��C and offers a degree of protection rated at IP67. The net width of the switch is 90 mm, and it has a rated voltage (AC) of 36Vac.
