SP150YPQ Banner Signal Beacons
Part#:SP150YPQ
Alt. Part#:13642
Manufacturer:Banner
Category:Signal Beacons
Product Lifecycle:Active
Product description
EZ-LIGHT Traffic Series: 1-Indicator Daylight Visible; Voltage: 15-30 V dc; Housing: Polycarbonate; IP67; Input: PNP/NPN Selectable; Color: Yellow; 4-pin M12 Integral QD
Product Details
- Weight 272.1552 g
- Country Of Origin US
- Mounting Thread No Thread
- Lumens Color 1 14.0
- Housing Style Flat Mount - Signal Light
- Connection Integral QD
- Physical Dimensions (LxWxH or DxH mm) 109.5 x 80.9 x 91.6
- Feature: Quick Disconnect Yes
- Color Input Control Individual (One wire/color, same number of colors as input wires)
- Number of Input Pins/Conductors 4
- Feature: Hazardous Area No
- Wireless No
- Indication Yes
- Quick Disconnect Type M12 (Euro)
- Max Op. Temperature (°C) 50
- Multi-Color Device Single Color On
- Product Size (mm) Other
- Color 1 - Wavelength/Color Temp/Coordinates 590 nm
- Feature: Audible No
- Modbus RTU No
- Power DC
- Color Technology Standard LED
- Supply Voltage 15-30 V dc
- Feature: Chemical Resistant No
- Primary Housing Material Polycarbonate
- Max Current Color (mA) 120
- Min Op. Temperature (°C) -40
- Pro-Editor Compatible (Discrete) No
- Power Source DC
- Color Option 1 Yellow
- Input Type Bimodal (PNP/NPN)
- Indication Intensity High Brightness & Daylight Visible
- Number of Colors / Segments 1
- Animation Option 1 Solid On
- Max Input Response Time (ms) 10
- Application: Traffic Light Yes
- Environmental Rating IP67
- IO Link No
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of SP150YPQ on Powermatic Associates is $153.00. Order now.
About the product
Banner Engineering SP150YPQ is a traffic light from the EZ-LIGHT series designed with a 1-tier 1-color yellow LED illumination. It features a polycarbonate (PC) base and is housed in black. This LED traffic signal light is pre-equipped with a 4-pin M12 Euro-style QD connector for connectivity. It operates on a supply voltage of 15Vdc-30Vdc (24Vdc nom.) and can be mounted on surfaces or walls. The SP150YPQ is designed to operate in ambient air temperatures ranging from -40°C to +50°C and offers a degree of protection rated at IP67. It consumes 120mA of current and includes 1 x digital input (15-30Vdc; PNP) for color control.
