T18-2VPLPC-9M Banner Proximity Sensors
Part#:T18-2VPLPC-9M
Alt. Part#:802633
Manufacturer:Banner
Category:Proximity Sensors
Product Lifecycle:Active
Product description
T18-2 Series: Polarized Retroreflective with pot; Range: variable to 6 m; Input: 10-30 V dc; Outputs: complementary PNP; 9 m 4-conductor PVC Cable
Product Details
- Weight 340.194 g
- Country Of Origin MX
- Sensing Beam Visible Red LED
- Max Op. Temp. (°C) 70
- Special Feature: Remote Teach No
- Lens Material Acrylic
- Sensing Mode (General) Retroreflective
- IP Rating IP67, IP68, IP69
- Feature: Timing (Hold/Delay) No
- Quick Disconnect Type No QD
- Repeatability (µs) 100
- Housing Style Barrel
- Operation Light/Dark Operate
- NEMA Rating NEMA 6P
- Input/Output Discrete
- Max Sensing Distance (mm) 6000
- Primary Housing Material Thermoplastic
- Power DC
- Output response time (ms) 1.5
- Special Feature: Water Detection No
- Barrel Diameter (mm) 18
- Cable Length (m) 9
- Sensing Mode (Detailed) Polarized
- Min Op. Temp. (°C) -40
- Special Feature: Intrinsically Safe No
- Connection Cable
- Delay at Power-up (ms) 500
- Power Supply/Supply Voltage 10-30 V dc
- Sensing Beam Wavelength 624
- Opposed Mode Emitter/Receiver N/A
- DeviceNet No
- Outputs PNP
- Feature: Washdown Rated Yes
- Feature: Encapsulated Yes
- IO Link No
- Adjustments Potentiometer
- Feature: Audible No
- Indicator Indicator LEDs
- Feature: Ecolab Certified Yes
- Max Op. Relative Humidity [%] 95% @ 50°C
- Feature: Chemical Resistant Yes
- Number of Pins 4
- Feature: Hazardous Area No
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of T18-2VPLPC-9M on Powermatic Associates is $148.00. Order now.
About the product
Banner Engineering T18-2VPLPC-9M is a polarized photo-electric sensor from the T18-2 series, designed in a retro-reflective mode with potentiometer adjustment for range setting. It features a thermoplastic housing and an acrylic lens. This sensor is pre-wired with a 9m cable that terminates with bare end flying leads. It operates on a supply voltage of 10Vdc to 30Vdc, with nominal voltages of 12Vdc and 24Vdc. The ambient air temperature range for operation is from -40 to +70 degrees Celsius. It offers a high degree of protection with ratings of IP67, IP68, IP69K, and NEMA 6P, making it suitable for harsh environmental conditions. The sensor has an M18 cylindrical threaded/barrel shape, includes 1 x digital output (PNP transistor; complementary), and provides a sensing distance of up to 6m. It emits visible red light and has a response time of 1.5ms or 0.0015 seconds. The operating modes available are Light-ON and Dark-ON, with a thread size of M18.
