T30AW3RQ1 Banner Proximity Sensors
Part#:T30AW3RQ1
Alt. Part#:33446
Manufacturer:Banner
Category:Proximity Sensors
Product Lifecycle:Active
Product description
EZ-BEAM T30 Series: Receiver; Range: 60 m; Input: 20-250 V ac; Output: SPST Solid-state Light Operate; 4-pin Micro Integral QD
Product Details
- Weight 90.264808 g
- Country Of Origin US
- Sensing Mode (General) Opposed
- Min Op. Temp. (°C) -40
- Repeatability (µs) 2000
- Indicator LEDs
- Input/Output Solid-State AC Switch
- Power Supply/Supply Voltage 20-250 V ac
- Delay at Power-up (ms) 100
- Barrel Diameter (mm) 30
- Housing Style Barrel
- Operation Light Operate
- IP Rating IP69
- DeviceNet No
- Feature: Washdown Rated Yes
- Outputs Solid-State AC Switch
- Max Op. Temp. (°C) 70
- Number of Pins 4
- Opposed Mode Emitter/Receiver Receiver
- Power AC
- Special Feature: Intrinsically Safe No
- Quick Disconnect Type 1/2 in. (Micro)
- NEMA Rating NEMA 6P
- Feature: Ecolab Certified Yes
- Primary Housing Material Thermoplastic
- Special Feature: Remote Teach No
- Max Op. Relative Humidity [%] 90% @ 50°C
- Feature: Timing (Hold/Delay) No
- Sensing Mode (Detailed) Receiver
- Connection Integral QD
- Special Feature: Water Detection No
- Adjustments N/A
- Feature: Audible No
- Max Sensing Distance (mm) 60000
- Sensing Beam Infrared LED
- Output response time (ms) 16 ON/8 OFF
- Lens Material Acrylic
- Feature: Encapsulated Yes
- IO Link No
- Feature: Hazardous Area No
- Feature: Chemical Resistant No
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of T30AW3RQ1 on Powermatic Associates is $106.00. Order now.
About the product
Banner Engineering T30AW3RQ1 is a photo-electric sensor designed as part of the T30 series, featuring a through-beam system in an opposed mode configuration. This sensor functions as a receiver alone, housed in a thermoplastic material. It comes pre-equipped with a 4-pin 1/2" micro connector for connectivity. The sensor operates on a supply voltage ranging from 20Vac to 250Vac, with nominal values at 200Vac, 220Vac, and 240Vac. It is designed to function within an ambient air temperature range of -40 to +70°C and offers a degree of protection rated at IP69K NEMA 6P. The T30AW3RQ1 has an M30 cylindrical threaded/barrel shape, includes 1 x digital output with a solid-state AC output and SPST contact type, and boasts a sensing distance of up to 60 meters. It utilizes infrared light with a wavelength of 950 nm and has a response time of 16ms (0.016 s). Its operating mode is Light-ON, and it features an M30 thread size.
