VS3AN5XLP Banner Proximity Sensors
Part#:VS3AN5XLP
Alt. Part#:62619
Manufacturer:Banner
Category:Proximity Sensors
Product Lifecycle:Active
Product description
VS3 Series: Polarized Retro; Range: 250 mm; Input: 10-30 V dc; Output: NPN Light Operate; 2 m (6.5 ft) Cable
Product Details
- Weight 54.43104 g
- Country Of Origin MX
- Sub-range name VS3 series
- Sensing distance 250mm
- Connection type Pre-wired with 6.5ft / 2m cable terminated with bare end flying leads
- Degree of protection IP67 NEMA 6
- Order code / Manufacturer SKU 62619
- Supply voltage (DC) 10Vdc-30Vdc (12Vdc / 24Vdc nom.)
- Light Color Visible red
- Operating mode Light-ON NO (Normally Open)
- Primary brand Banner Engineering
- Functions Polarized (coaxial) photo-electric sensor green LED (power ON) yellow LED (light sensed)
- Material thermoplastic housing Glass lns. Acrylic lid cover
- Main function Sensor (Photo-electric)
- Design retro-reflective mode
- Shape Rectangular
- Response time 1ms / 0.001 s
- Compliant with standard(s) CE
- Wavelength 680 nm
- Digital outputs 1 x digital output (NPN transistor)
- Ambient air temperature for operation -20...+55 °C
- Housing Style Rectangular
- Output response time (ms) 1
- NEMA Rating NEMA 6
- Opposed Mode Emitter/Receiver N/A
- Delay at Power-up (ms) 150
- Feature: Chemical Resistant No
- Cable Length (m) 2
- Connection Cable
- Special Feature: Water Detection No
- Indicator LEDs
- DeviceNet No
- Primary Housing Material Thermoplastic
- Min Op. Temp. (°C) -20
- Max Op. Relative Humidity [%] 80% @ 50°C
- Feature: Hazardous Area No
- Sensing Mode (General) Retroreflective
- Operation Light Operate
- IP Rating IP67
- Max Sensing Distance (mm) 250
- Power Supply/Supply Voltage 10-30 V dc
- Special Feature: Remote Teach No
- Lens Material Glass
- Sensing Mode (Detailed) Polarized (Coaxial)
- Max Op. Temp. (°C) 55
- Adjustments N/A
- Feature: Audible No
- Input/Output Discrete
- Number of Pins 3
- Feature: Encapsulated No
- Sensing Beam Visible Red LED
- Outputs NPN
- Special Feature: Intrinsically Safe No
- Feature: Timing (Hold/Delay) No
- Power DC
- Quick Disconnect Type No QD
- Repeatability (µs) 160
- Barrel Diameter (mm) N/A
- IO Link No
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of VS3AN5XLP on Powermatic Associates is $140.00. Order now.
About the product
Banner Engineering VS3AN5XLP is a polarized (coaxial) photo-electric sensor designed for retro-reflective mode operation. It features a thermoplastic housing, glass lens, and an acrylic lid cover. This sensor offers a degree of protection rated at IP67 and NEMA 6, making it suitable for various environmental conditions with an ambient air temperature range for operation between -20 and +55 °C. It operates in Light-ON NO (Normally Open) mode and includes 1 x digital output (NPN transistor) with a response time of 1ms / 0.001 s. The VS3AN5XLP is equipped with a pre-wired 6.5ft / 2m cable terminated with bare end flying leads for connectivity. Its rectangular shape and visible red light, with a wavelength of 680 nm, complement its design. The sensor supports a supply voltage range of 10Vdc-30Vdc (12Vdc / 24Vdc nom.) and has a sensing distance of 250mm. It belongs to the VS3 series.
